HCD-GN600
Pin NamePin No. I/O
Discription
54 ALC O ALC signal output
55 TC-RELAY O REC/PB selection signal output
56 REC BIAS O Bias on/off signal output
57 CAPM-CONT O Capstan motor REV/FWD/STOP control signal output
58 B-TRIG O TCM-B Trigger output
59 A-TRIG O TCM-A trigger output
60 B-REC, REV O Record tab switch for SIDE B signal output
61 B-PLAY I TCM-B play switch input
62 VCC — Power supply (+3.3V)
––––––––––––––
63 AMS-IN I AMS signal input
64 VSS — Ground
65 ST-DIN I Tuner data input
66 A-REC, FWD O Record tab switch for SIDE A signal output
67 A-HALF I A deck half detection signal input
68 A-PLAY I TCM-A play switch input
69 LED-SW-LINK O Subwoofer LED drive signal output (open)
70 LED-SW-ON O Subwoofer LED drive signal output (open)
71 LED-MATRIX-SURR-2 O Subwoofer LED drive signal output (open)
72 LED-MATRIX-SURR-1 O Subwoofer LED drive signal output (open)
73 KEY-DISPLAY I DISPLAY key signal input
74 POWER-KEY I Power key signal input
75 STK-MUTE O Mute signal output to power IC
––––––––––––––––––
76 HP-MUTE O Headphone mute signal output
77 LINE-MUTE O TA LINE mute signal output
––––––––––––––––––
78 PROTECT I Speaker protection signal input
79 AUDIO-DATA O Serial data output to Audio EQIC
80 AUDIO-CLK O Serial data clock output to Audio EQIC
––––––––––––––––
81 VACS IN I VACS signal input
82 SW-RELAY O Subwoofer relay control signal output (open)
83 FRONT-RELAY O Front speaker relay driver signal output
84 LINK-RELAY O Surround speaker relay driver signal output
–––––––––––––––
85 STEREO I Stereo signal input
––––––––––––––
86 TUNED I Tuned signal input
87 ST-CE O Tuner chip enable signal output
88 ST-DOUT O Tuner data output
89 A-SHUT I TCM-A reel pulse input
90 B-SHUT I TCM-B reel pulse input
91 B-HALF I B deck half detection input
92 MODEL-IN I Model input
93 DEST-IN I Destination input
94 I-HOLD I Over-voltage protection detection input termnal
95 SW-AD-KEY I Subwoofer key signal input (fixed at “H”)
96 AVSS — Ground
97 ST-CLK O Tuner clock signal output
98 VREF I Reference voltage input
99 AVCC — Power supply (+3.3V)
100 ST-MUTE O Tuner mute signal output
