63
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN600
MAIN
A-4731-327-A GAME IN BOARD, COMPLETE
************************
< CAPACITOR >
C604 1-124-257-00 ELECT 2.2uF 20% 50V
C606 1-124-257-00 ELECT 2.2uF 20% 50V
C630 1-162-294-31 CERAMIC 0.001uF 10% 50V
C631 1-162-294-31 CERAMIC 0.001uF 10% 50V
C634 1-162-294-31 CERAMIC 0.001uF 10% 50V
C635 1-162-294-31 CERAMIC 0.001uF 10% 50V
C715 1-162-215-31 CERAMIC 47PF 5% 50V
C716 1-162-215-31 CERAMIC 47PF 5% 50V
C717 1-124-584-00 ELECT 100uF 20% 10V
C718 1-124-584-00 ELECT 100uF 20% 10V
C719 1-124-257-00 ELECT 2.2uF 20% 50V
C736 1-124-261-00 ELECT 10uF 20% 50V
C737 1-124-261-00 ELECT 10uF 20% 50V
C738 1-124-257-00 ELECT 2.2uF 20% 50V
C739 1-162-215-31 CERAMIC 47PF 5% 50V
C740 1-162-282-31 CERAMIC 100PF 10% 50V
C741 1-124-250-11 ELECT 0.15uF 20% 50V
C742 1-162-215-31 CERAMIC 47PF 5% 50V
C743 1-162-290-31 CERAMIC 470PF 10% 50V
C744 1-162-294-31 CERAMIC 0.001uF 10% 50V
C747 1-124-257-00 ELECT 2.2uF 20% 50V
C748 1-161-494-00 CERAMIC 0.022uF 25V
C749 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN606 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN607 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< GROUND TERMINAL >
EP701 1-537-738-21 TERMINAL, GROUND
EP703 1-537-738-21 TERMINAL, GROUND
< IC >
IC722 8-759-167-88 IC NJM4565D
< JACK >
J601 1-764-592-11 JACK 3P (GAME INPUT)
J631 1-794-702-11 JACK, HEADPHONE (PHONES)
J721 1-817-629-11 JACK (LARGE TYPE) (MIC)
< TRANSISTOR >
Q721 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
< RESISTOR >
R602 1-249-417-11 CARBON 1K 5% 1/4W F
R603 1-249-417-11 CARBON 1K 5% 1/4W F
R604 1-249-441-11 CARBON 100K 5% 1/4W
R605 1-249-441-11 CARBON 100K 5% 1/4W
R721 1-249-429-11 CARBON 10K 5% 1/4W
R722 1-249-432-11 CARBON 18K 5% 1/4W
R734 1-247-807-31 CARBON 100 5% 1/4W
R735 1-247-885-00 CARBON 180K 5% 1/4W
R736 1-249-429-11 CARBON 10K 5% 1/4W
R737 1-249-433-11 CARBON 22K 5% 1/4W
R738 1-249-417-11 CARBON 1K 5% 1/4W F
R739 1-249-441-11 CARBON 100K 5% 1/4W
R740 1-249-421-11 CARBON 2.2K 5% 1/4W F
R742 1-249-417-11 CARBON 1K 5% 1/4W F
R743 1-249-429-11 CARBON 10K 5% 1/4W
R744 1-249-441-11 CARBON 100K 5% 1/4W
R745 1-247-807-31 CARBON 100 5% 1/4W
R746 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV722 1-227-452-11 RES, VAR, CARBON 50K (MIC LEVEL)
*************************************************************
A-4731-339-A MAIN BOARD, COMPLETE
*********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C101 1-126-933-11 ELECT 100uF 20% 16V
C102 1-126-964-11 ELECT 10uF 20% 50V
C103 1-126-964-11 ELECT 10uF 20% 50V
C104 1-126-964-11 ELECT 10uF 20% 50V
C105 1-126-795-11 ELECT 10uF 20% 50V
C106 1-136-157-00 FILM 0.022uF 5% 50V
C107 1-136-157-00 FILM 0.022uF 5% 50V
C108 1-136-159-00 FILM 0.033uF 5% 50V
C109 1-115-871-11 ELECT 1uF 20% 50V
C110 1-137-150-11 MYLAR 0.01uF 5% 100V
C111 1-126-795-11 ELECT 10uF 20% 50V
C112 1-136-169-00 FILM 0.22uF 5% 50V
C113 1-136-171-00 FILM 0.33uF 5% 50V
C114 1-126-964-11 ELECT 10uF 20% 50V
C115 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C116 1-126-933-11 ELECT 100uF 20% 16V
C117 1-126-961-11 ELECT 2.2uF 20% 50V
C130 1-126-964-11 ELECT 10uF 20% 50V
C121 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C122 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C131 1-126-959-11 ELECT 0.47uF 20% 50V
C132 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C140 1-136-495-11 FILM 0.068uF 5% 50V
C150 1-126-964-11 ELECT 10uF 20% 50V
C152 1-126-964-11 ELECT 10uF 20% 50V
C153 1-126-964-11 ELECT 10uF 20% 50V
C154 1-126-964-11 ELECT 10uF 20% 50V
C155 1-126-964-11 ELECT 10uF 20% 50V
C156 1-136-157-00 FILM 0.022uF 5% 50V
C157 1-136-157-00 FILM 0.022uF 5% 50V
C158 1-136-159-00 FILM 0.033uF 5% 50V
C159 1-115-871-11 ELECT 1uF 20% 50V
C160 1-137-150-11 MYLAR 0.01uF 5% 100V
C161 1-126-795-11 ELECT 10uF 20% 50V
C162 1-136-169-00 FILM 0.22uF 5% 50V
C163 1-136-171-00 FILM 0.33uF 5% 50V
C167 1-126-961-11 ELECT 2.2uF 20% 50V
C200 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C201 1-104-665-11 ELECT 100uF 20% 10V
C206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
