66
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN600
MAIN
Q621 8-729-802-80 TRANSISTOR 2SC3661-TB
Q650 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q651 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q652 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q670 8-729-802-80 TRANSISTOR 2SC3661-TB
Q671 8-729-802-80 TRANSISTOR 2SC3661-TB
Q851 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q852 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q901 8-729-040-20 TRANSISTOR RT1P137L-TP
Q902 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q903 8-729-209-60 TRANSISTOR 2SB1375
< RESISTOR >
R101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-220-373-11 METAL CHIP 620 5% 1/10W
R104 1-216-821-11 METAL CHIP 1K 5% 1/10W
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R110 1-216-864-11 METAL CHIP 0 5% 1/10W
R112 1-216-864-11 METAL CHIP 0 5% 1/10W
R117 1-216-845-11 METAL CHIP 100K 5% 1/10W
R118 1-216-821-11 METAL CHIP 1K 5% 1/10W
R121 1-216-821-11 METAL CHIP 1K 5% 1/10W
R122 1-216-821-11 METAL CHIP 1K 5% 1/10W
R130 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R131 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R132 1-216-857-11 METAL CHIP 1M 5% 1/10W
R133 1-216-845-11 METAL CHIP 100K 5% 1/10W
R134 1-218-701-11 METAL CHIP 2.4K 5% 1/10W
R140 1-216-833-11 METAL CHIP 10K 5% 1/10W
R141 1-216-809-11 METAL CHIP 100 5% 1/10W
R142 1-216-809-11 METAL CHIP 100 5% 1/10W
R150 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R151 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R152 1-216-833-11 METAL CHIP 10K 5% 1/10W
R153 1-220-373-11 METAL CHIP 620 5% 1/10W
R154 1-216-821-11 METAL CHIP 1K 5% 1/10W
R155 1-216-841-11 METAL CHIP 47K 5% 1/10W
R156 1-216-833-11 METAL CHIP 10K 5% 1/10W
R157 1-216-809-11 METAL CHIP 100 5% 1/10W
R167 1-216-845-11 METAL CHIP 100K 5% 1/10W
R168 1-216-821-11 METAL CHIP 1K 5% 1/10W
R204 1-216-833-11 METAL CHIP 10K 5% 1/10W
R205 1-216-821-11 METAL CHIP 1K 5% 1/10W
R206 1-216-839-11 RES CHIP 33K 5% 1/10W
R224 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R226 1-216-847-11 METAL CHIP 150K 5% 1/10W
R228 1-216-843-11 METAL CHIP 68K 5% 1/10W
R254 1-216-833-11 METAL CHIP 10K 5% 1/10W
R255 1-216-821-11 METAL CHIP 1K 5% 1/10W
R256 1-216-839-11 RES CHIP 33K 5% 1/10W
R284 1-216-853-11 METAL CHIP 470K 5% 1/10W
R285 1-216-837-11 METAL CHIP 22K 5% 1/10W
R286 1-216-837-11 METAL CHIP 22K 5% 1/10W
R301 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R302 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R303 1-216-833-11 METAL CHIP 10K 5% 1/10W
R304 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R305 1-216-841-11 METAL CHIP 47K 5% 1/10W
R306 1-216-837-11 METAL CHIP 22K 5% 1/10W
R307 1-216-857-11 METAL CHIP 1M 5% 1/10W
R308 1-216-809-11 METAL CHIP 100 5% 1/10W
R309 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R310 1-216-809-11 METAL CHIP 100 5% 1/10W
R312 1-216-809-11 METAL CHIP 100 5% 1/10W
R313 1-216-821-11 METAL CHIP 1K 5% 1/10W
R314 1-216-821-11 METAL CHIP 1K 5% 1/10W
R315 1-216-833-11 METAL CHIP 10K 5% 1/10W
R316 1-216-833-11 METAL CHIP 10K 5% 1/10W
R317 1-216-833-11 METAL CHIP 10K 5% 1/10W
R320 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R327 1-216-835-11 METAL CHIP 15K 5% 1/10W
R328 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R329 1-216-833-11 METAL CHIP 10K 5% 1/10W
R330 1-216-837-11 METAL CHIP 22K 5% 1/10W
R332 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R333 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R334 1-216-845-11 METAL CHIP 100K 5% 1/10W
R342 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0R343 1-219-787-17 FUSIBLE 5.6 5% 1/4W
0R344 1-219-787-17 FUSIBLE 5.6 5% 1/4W
R345 1-216-836-11 METAL CHIP 18K 5% 1/10W
R346 1-216-836-11 METAL CHIP 18K 5% 1/10W
R347 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R351 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R352 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R353 1-216-833-11 METAL CHIP 10K 5% 1/10W
R354 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R355 1-216-841-11 METAL CHIP 47K 5% 1/10W
R360 1-216-819-11 METAL CHIP 680 5% 1/10W
R361 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R362 1-216-833-11 METAL CHIP 10K 5% 1/10W
R363 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R364 1-216-819-11 METAL CHIP 680 5% 1/10W
R365 1-216-833-11 METAL CHIP 10K 5% 1/10W
R366 1-216-819-11 METAL CHIP 680 5% 1/10W
R367 1-216-833-11 METAL CHIP 10K 5% 1/10W
R368 1-216-833-11 METAL CHIP 10K 5% 1/10W
R369 1-216-833-11 METAL CHIP 10K 5% 1/10W
R370 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R371 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R372 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R373 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R374 1-216-833-11 METAL CHIP 10K 5% 1/10W
R375 1-216-833-11 METAL CHIP 10K 5% 1/10W
R376 1-216-833-11 METAL CHIP 10K 5% 1/10W
R377 1-216-833-11 METAL CHIP 10K 5% 1/10W
R378 1-216-833-11 METAL CHIP 10K 5% 1/10W
R379 1-216-833-11 METAL CHIP 10K 5% 1/10W
R380 1-216-837-11 METAL CHIP 22K 5% 1/10W
R382 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R387 1-216-833-11 METAL CHIP 10K 5% 1/10W
R388 1-216-837-11 METAL CHIP 22K 5% 1/10W
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
