68
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN600
R673 1-216-833-11 METAL CHIP 10K 5% 1/10W
R674 1-215-891-11 METAL OXIDE 680 5% 2W
R675 1-216-821-11 METAL CHIP 1K 5% 1/10W
R676 1-216-806-11 METAL CHIP 56 5% 1/10W
R851 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R852 1-216-833-11 METAL CHIP 10K 5% 1/10W
R853 1-216-422-11 METAL OXIDE 18 5% 1W
R854 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R901 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R902 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R903 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R904 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R905 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R906 1-216-821-11 METAL CHIP 1K 5% 1/10W
R908 1-216-833-11 METAL CHIP 10K 5% 1/10W
R913 1-216-841-11 METAL CHIP 47K 5% 1/10W
< VARIABLE RESISTOR >
RV301 1-238-019-11 RES, ADJ, CARBON 47K (REC LEVEL (L))
RV304 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS (L))
RV351 1-238-019-11 RES, ADJ, CARBON 47K (REC LEVEL (R))
RV354 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS (R))
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< VIBRATOR >
X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X502 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
*************************************************************
1-687-133-11 MOTOR (LD) BOARD
*****************
*************************************************************
1-687-134-11 MOTOR (TB) BOARD
*****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
*************************************************************
A-4731-347-A POWER AMP BOARD, COMPLETE
****************************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPASITOR >
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C502 1-162-294-31 CERAMIC 0.001uF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-104-665-11 ELECT 100uF 20% 10V
C507 1-136-495-11 FILM 0.068uF 5% 50V
C508 1-136-495-11 FILM 0.068uF 5% 50V
C509 1-128-560-11 ELECT 22uF 20% 100V
C512 1-162-306-11 CERAMIC 0.01uF 20% 16V
C513 1-164-159-11 CERAMIC 0.1uF 50V
C516 1-104-665-11 ELECT 100uF 20% 10V
C517 1-126-964-11 ELECT 10uF 20% 50V
C523 1-162-306-11 CERAMIC 0.01uF 30% 16V
C524 1-162-306-11 CERAMIC 0.01uF 30% 16V
C526 1-126-964-11 ELECT 10uF 20% 50V
C541 1-136-165-00 FILM 0.1uF 5% 50V
C542 1-127-811-11 ELECT 3300uF 20% 50V
C544 1-130-777-00 MYLAR 0.1uF 5% 100V
C545 1-130-777-00 MYLAR 0.1uF 5% 100V
C546 1-137-843-11 ELECT 2200uF 20% 100V
C551 1-126-963-11 ELECT 4.7uF 20% 50V
C552 1-162-294-31 CERAMIC 0.001uF 10% 50V
C553 1-162-282-31 CERAMIC 100PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20% 10V
C557 1-136-495-11 FILM 0.068uF 5% 50V
C558 1-136-495-11 FILM 0.068uF 5% 50V
C559 1-128-560-11 ELECT 22uF 20% 100V
C581 1-126-965-91 ELECT 22uF 20% 50V
C591 1-136-165-00 FILM 0.1uF 5% 50V
C592 1-127-811-11 ELECT 3300uF 20% 50V
C596 1-137-843-11 ELECT 2200uF 20% 100V
< CONNECTOR >
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN504 1-770-722-11 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-72
D502 8-719-991-33 DIODE 1SS133T-72
D503 8-719-947-70 DIODE MTZJ-T-72-18C
D504 8-719-947-70 DIODE MTZJ-T-72-18C
D506 8-719-991-33 DIODE 1SS133T-72
D507 8-719-991-33 DIODE 1SS133T-72
D508 8-719-991-33 DIODE 1SS133T-72
D509 8-719-991-33 DIODE 1SS133T-72
D511 8-719-991-33 DIODE 1SS133T-72
D541 8-719-510-68 DIODE D5SBA204101
D543 8-719-500-60 DIODE D5SBA20
D551 8-719-991-33 DIODE 1SS133T-72
D581 8-719-991-33 DIODE 1SS133T-72
< EARTH TERMINAL >
* EP501 1-537-738-21 TERMINAL, EARTH
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 6-600-169-01 IC STK412-240
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q505 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q506 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q510 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q511 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q514 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q516 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q517 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q518 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
MAIN
MOTOR (LD) MOTOR (TB) POWER AMP
