71
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN600
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
< SWITCH >
S748 1-476-504-11 ENCODER, ROTARY (VOLUME)
S750 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S759 1-762-875-21 SWITCH, KEYBOARD (SURROUND SPEAKER
MODE)
S760 1-762-875-21 SWITCH, KEYBOARD (P.FILE)
S761 1-762-875-21 SWITCH, KEYBOARD (ILLUMINATION)
S762 1-762-875-21 SWITCH, KEYBOARD (GAME EQ)
S763 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S765 1-762-875-21 SWITCH, KEYBOARD (EDIT/DIRECTION)
S766 1-762-875-21 SWITCH, KEYBOARD (FM MODE/REPEAT)
S767 1-762-875-21 SWITCH, KEYBOARD (TUNER MEMORY/PLAY
MODE)
S768 1-762-875-21 SWITCH, KEYBOARD (AMP MENU)
S769 1-762-875-21 SWITCH, KEYBOARD (MUSIC EQ)
S770 1-762-875-21 SWITCH, KEYBOARD (MOVIE EQ)
S771 1-762-875-21 SWITCH, KEYBOARD (EFFECT ON/OFF)
S773 1-786-528-11 SWITCH, ROTARY (<,,,M,m,PUSH ENTER)
************************************************************
MISCELLANEOUS
***************
5 1-920-838-32 WIRE (FLAT TYPE) (11 CORE)
6 1-693-603-11 TUNER (FM/AM)
70 1-773-040-11 WIRE (FLAT TYPE) (17 CORE)
73 1-773-110-11 WIRE (FLAT TYPE) (19 CORE)
75 1-796-487-31 DECK, MECHANICAL
79 1-751-688-11 WIRE (FLAT TYPE) (13 CORE)
0103 1-777-071-53 CORD, POWER (E51)
0103 1-783-941-12 CORD, POWER (AR)
0103 1-791-901-12 CORD, POWER (E2,MX)
152 1-776-182-11 WIRE (FLAT TYPE) (5 CORE)
226 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
227 1-775-280-11 WIRE (FLAT TYPE) (31 CORE)
0229 A-4735-357-A BASE ASSY, OP (including KSS-213DCP)
230 1-471-035-11 MAGNET ASSY
0F974 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
0F975 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
0F976 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
0F977 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V)
0F978 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) (T4AL 250V)
M741 A-4723-963-A MOTOR ASSY, TABLE
M751 A-4737-553-A MOTOR ASSY, LOADING
M891 1-763-072-11 FAN, DC
RE701 1-477-680-11 ENCODER, ROTARY
0T910 1-439-556-11 POWER TRANSFORMER
