Sony HCD-GN600 - 3-1. CASE Disassembly; 3-2. LOADING (PANEL) Disassembly

8
HCD-GN600
Note: Follow the disassembly procedure in the numerical order given.
3-1. CASE
3-2. LOADING (PANEL)
1 Three screws
(case 3 TP2)
2 Five screws
(+BVTT3 x 6)
6 Case
5
4
1
Three screws
(case 3 TP2)
3 Two screws
(+BVTT3 x 6
)
CD mechanismdeck (CDM74-K6BD47S)
1 Turn the pulley to the arrow direction.
Front side
Pulley
4 Loading (panel)
3
2
Pull out disc tray
