3-5. MAIN Board, TRANSFORMER Board
3-6. LOADING Board
5 LOADING board
2 two screws (+BTP 2.6 × 6)
4 motor (LD) assy
(M901)
1 Remove the belt.
3 Remove soldering from the two points.
1 connector 9p (CN801)
5 main heat sink
8 sub heat sink
9 MAIN board
2 two s crews (+BVTP 3 × 10)
7 two s crews
(+BVTP 3
× 10)
6 two s crews
(+BVTP 3
× 10)
4 two s crews
(+BVTP 3
× 10)
3 three s crews
(+BVTP 3
× 10
)
q; four s crews
(+BVTP 3
× 10)
qs TRANSFORMER
board
qa power transformer
