Sony HCD-GP5 - Front Panel Assembly Removal

8
HCD-GP5
3-2. Front Panel Assy
3-3. CONTROL Board, Single Cassette Mechanism
5 w ire (flat type) 13p (CN303)
4 four s crews
(+BVTP 3
× 10)
3 two s crews
(+KTP 3
× 12)
6 w ire (flat type) 26p (CN302)
q; front panel assy
7 connector 5p (CN1)
1 four claws
2 CD lid
9 connector 5p (CN201)
8 connector 6p
q; single cassette mechanism
(CMAL1Z240A)
7 CONTROL board
1 three s crews (+BVTP 3 × 10)
2 four s crews (+BVTP 3 × 10)
3 four s crews (+BVTP 3 × 10)
8 four s crews
(+BVTP 3
× 10)
4 w ire (flat type) 26p (CN601)
5 w ire (flat type) 13p (CN602)
6 w ire (flat type) 8p (CN603)
9 two clamp
