Sony HCD-GP5 - Optical Pick-up and Holder Removal

12
HCD-GP5
3-9. Optical Pick-up (KSM-213D), Holder (C213)
1 two floating screw
s
(+PTPWH M2.6)
qf floating screws
(+PTPWH M2.6)
qg holder (C213)
5 screw (+PTTP M2.6)
6 stopper (BU)
2 two compression spring (T213)
7 compression spring
(T213)
3 insulator
8 insulator
9 screw (+PTTP M2.6)
q; stopper (BU)
qa compression spring
(T213)
qs insulator
qd optical pick-up
(KSM-213D)
4 insulator
Ver 1.2 2003.11
