Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
45
HCD-GP5
R675 1-216-837-11 METAL CHIP 22K 5% 1/10W
R676 1-216-837-11 METAL CHIP 22K 5% 1/10W
R677 1-216-839-11 METAL CHIP 33K 5% 1/10W
R678 1-216-837-11 METAL CHIP 22K 5% 1/10W
R679 1-218-179-11 RES-CHIP 10M 5% 1/10W
R680 1-216-821-11 METAL CHIP 1K 5% 1/10W
R681 1-216-821-11 METAL CHIP 1K 5% 1/10W
R682 1-249-415-11 CARBON 680 5% 1/4W
R683 1-216-845-11 METAL CHIP 100K 5% 1/10W
R684 1-249-426-11 CARBON 5.6K 5% 1/4W
R685 1-216-845-11 METAL CHIP 100K 5% 1/10W
R686 1-218-817-11 METAL CHIP 3.3 10% 1/2W
R687 1-249-426-11 CARBON 5.6K 5% 1/4W
R688 1-249-429-11 CARBON 10K 5% 1/4W
R689 1-216-809-11 METAL CHIP 100 5% 1/10W
R690 1-216-809-11 METAL CHIP 100 5% 1/10W
R691 1-247-807-31 CARBON 100 5% 1/4W
R692 1-216-809-11 METAL CHIP 100 5% 1/10W
R693 1-216-809-11 METAL CHIP 100 5% 1/10W
R694 1-216-809-11 METAL CHIP 100 5% 1/10W
R695 1-216-809-11 METAL CHIP 100 5% 1/10W
R696 1-216-809-11 METAL CHIP 100 5% 1/10W
R697 1-247-807-31 CARBON 100 5% 1/4W
R698 1-247-807-31 CARBON 100 5% 1/4W
R699 1-247-807-31 CARBON 100 5% 1/4W
R700 1-216-295-91 SHORT CHIP 0 (US, CND, AEP, UK, KR)
R700 1-216-837-11 METAL CHIP 22K 5% 1/10W
(E51, HK, SP, TW, AUS)
R701 1-216-833-11 METAL CHIP 10K 5% 1/10W
(US, CND, AEP, UK, KR)
R702 1-216-837-11 METAL CHIP 22K 5% 1/10W
(E51, HK, SP, TW, AUS)
R702 1-247-831-91 CARBON 1K 5% 1/4W
(US, CND, AEP, UK, KR)
R703 1-249-425-11 CARBON 4.7K 5% 1/4W
R704 1-249-425-11 CARBON 4.7K 5% 1/4W
R705 1-216-845-11 METAL CHIP 100K 5% 1/10W
R706 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R707 1-249-430-11 CARBON 12K 5% 1/4W
R708 1-216-840-11 METAL CHIP 39K 5% 1/10W
R709 1-216-833-11 METAL CHIP 10K 5% 1/10W
R710 1-247-831-91 CARBON 1K 5% 1/4W
R711 1-218-833-11 METAL CHIP 270 0.5% 1/10W
R712 1-247-831-91 CARBON 1K 5% 1/4W
R713 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R714 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R715 1-249-422-11 CARBON 2.7K 5% 1/4W
R716 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R717 1-249-427-11 CARBON 6.8K 5% 1/4W
R718 1-216-834-11 METAL CHIP 12K 5% 1/10W
R719 1-249-419-11 CARBON 1.5K 5% 1/4W
R720 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R721 1-249-422-11 CARBON 2.7K 5% 1/4W
R722 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R723 1-247-831-91 CARBON 1K 5% 1/4W
R724 1-249-426-11 CARBON 5.6K 5% 1/4W
R725 1-216-845-11 METAL CHIP 100K 5% 1/10W
R726 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R727 1-216-845-11 METAL CHIP 100K 5% 1/10W
R728 1-216-845-11 METAL CHIP 100K 5% 1/10W
R729 1-247-831-91 CARBON 1K 5% 1/4W
R734 1-216-838-11 METAL CHIP 27K 5% 1/10W
R735 1-247-879-91 CARBON 100K 5% 1/4W
R736 1-247-879-91 CARBON 100K 5% 1/4W
< SWITCH >
S601 1-786-050-21 SWITCH, KEY BOARD (TUNER/BAND)
S602 1-786-050-21 SWITCH, KEY BOARD (bB TAPE)
S603 1-786-050-21 SWITCH, KEY BOARD (MD)
S604 1-786-050-21 SWITCH, KEY BOARD (Z)
S605 1-786-050-21 SWITCH, KEY BOARD (x)
S606 1-786-050-21 SWITCH, KEY BOARD (+ M>)
S607 1-786-050-21 SWITCH, KEY BOARD (.m -)
S608 1-786-050-21 SWITCH, KEY BOARD (~/1)
S609 1-786-050-21 SWITCH, KEY BOARD (DISPLAY)
S610 1-786-050-21 SWITCH, KEY BOARD
(PLAY MODE/TUNING MODE)
S611 1-786-050-21 SWITCH, KEY BOARD (CD SYNC)
S612 1-786-050-21 SWITCH, KEY BOARD (z REC PAUSE/START)
S613 1-786-050-21 SWITCH, KEY BOARD (CD u)
S614 1-786-050-21 SWITCH, KEY BOARD (DSG)
S615 1-786-050-21 SWITCH, KEY BOARD (VOL+)
S616 1-786-050-21 SWITCH, KEY BOARD (VOL-)
< VIBRATOR >
X601 9-300-001-87 VIB, XTAL 32.768KHZ CFS-308 CT (32.768kHz)
X602 1-795-880-11 VIBRATOR, CERAMIC (8.64MHz)
************************************************************
1-689-576-11 HEADPHONE BOARD
*****************
< JACK >
J202 1-816-219-11 JACK, HEADPHONE (PHONES)
< COIL >
L205 1-414-142-11 INDUCTOR 1uH
< RESISTOR >
R201 1-249-409-11 CARBON 220 5% 1/4W
R202 1-249-412-11 CARBON 390 5% 1/4W
R203 1-249-409-11 CARBON 220 5% 1/4W
R204 1-249-412-11 CARBON 390 5% 1/4W
************************************************************
1-674-336-12 LOADING BOARD
*************
< CONNECTOR >
* CN151 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-786-203-11 SWITCH, LEVER (SLIDE)(OPEN/CLOSE)
************************************************************
CONTROL HEADPHONE LOADING
Ver. 1.6
