Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
47
HCD-GP5
C504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C505 1-113-342-11 CERAMIC 0.1uF 50V
C506 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C507 1-126-157-11 ELECT 10uF 20% 16V
C508 1-126-157-11 ELECT 10uF 20% 16V
C509 1-126-968-11 ELECT 100uF 20% 50V
C510 1-124-261-00 ELECT 10uF 20% 25V
C511 1-124-261-00 ELECT 10uF 20% 25V
C512 1-128-817-21 CERAMIC 470PF 5% 50V
C513 1-128-817-21 CERAMIC 470PF 5% 50V
C514 1-130-481-91 FILM 0.0068uF 5% 50V
C515 1-130-481-91 FILM 0.0068uF 5% 50V
C516 1-126-947-11 ELECT 47uF 20% 35V
C517 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C518 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C519 1-126-962-11 ELECT 3.3uF 20% 50V
C520 1-126-967-11 ELECT 47uF 20% 50V
< CONNECTOR >
* CN201 1-564-520-11 PLUG, CONNECTOR 5P
CN301 1-564-709-11 PIN, CONNECTOR (SMALL TYPE) 7P
CN302 1-779-294-11 CONNECTOR, FFC (LIF (NON-ZIF)) 26P
CN303 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN304 1-784-772-11 CONNECTOR, FFC 11P (EXCEPT AEP, UK, KR)
CN304 1-784-776-11 CONNECTOR, FFC 15P (AEP, UK, KR)
CN305 1-568-838-11 CONNECTOR, FFC 21P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-010-32 DIODE UZ-4.7BSA
D303 8-719-923-38 DIODE MTZJ-T-77-5.6B
D304 8-719-010-32 DIODE UZ-4.7BSA
D402 6-500-382-01 DIODE RL203GW-TA
D403 6-500-382-01 DIODE RL203GW-TA
D404 6-500-378-01 DIODE 1N5402GW (F20)
D405 6-500-378-01 DIODE 1N5402GW (F20)
D406 6-500-378-01 DIODE 1N5402GW (F20)
D407 6-500-378-01 DIODE 1N5402GW (F20)
D408 6-500-376-01 DIODE 1N4003LES
D409 6-500-376-01 DIODE 1N4003LES
D410 6-500-376-01 DIODE 1N4003LES
D411 8-719-983-35 DIODE MTZJ-T-77-33D
D412 6-500-376-01 DIODE 1N4003LES
D413 6-500-382-01 DIODE RL203GW-TA
D414 8-719-991-33 DIODE 1SS133T-77
D415 8-719-110-09 DIODE RD8.2ESB3
D416 6-500-335-01 DIODE MC2838-T112-1
D417 6-500-382-01 DIODE RL203GW-TA
D418 8-719-923-38 DIODE MTZJ-T-77-5.6B
D419 8-719-991-33 DIODE 1SS133T-77
D420 8-719-991-33 DIODE 1SS133T-77
D421 8-719-109-89 DIODE RD5.6ESB2
D422 8-719-921-63 DIODE MTZJ-7.5B
D423 6-500-382-01 DIODE RL203GW-TA
D425 8-719-110-09 DIODE RD8.2ESB3
D427 6-500-382-01 DIODE RL203GW-TA
D428 8-719-991-33 DIODE 1SS133T-77
D429 8-719-991-33 DIODE 1SS133T-77
D430 8-719-048-55 DIODE MTZJ-T-77-10C
D431 6-500-335-01 DIODE MC2838-T112-1
D432 6-500-334-01 DIODE MC2836-T112-1
D433 8-719-991-33 DIODE 1SS133T-77
D434 8-719-110-09 DIODE RD8.2ESB3
D435 8-719-991-33 DIODE 1SS133T-77
D501 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB202 1-410-396-41 FERRITE 0.45uH
FB203 1-410-396-41 FERRITE 0.45uH
FB301 1-412-473-21 INDUCTOR (SMALL TYPE)
FB302 1-412-473-21 INDUCTOR (SMALL TYPE)
FB303 1-412-473-21 INDUCTOR (SMALL TYPE)
FB304 1-412-473-21 INDUCTOR (SMALL TYPE)
< IC >
IC201 6-703-084-01 IC STK403-030-E (AEP, UK, KR)
IC201 6-704-106-01 IC STK403-040-E (EXCEPT AEP, UK, KR)
IC301 6-702-895-01 IC BD3881FV
< JACK >
J201 1-793-478-11 JACK, PIN 2P (MD)
J203 1-537-240-31 TERMINAL BOARD (CHECKER PIN)(SPEAKERS)
J204 1-774-785-21 JACK, PIN 1P (SUB WOOFER)
< COIL >
L201 1-456-107-11 COIL, AIR-CORE
L202 1-456-107-11 COIL, AIR-CORE
L203 1-408-117-00 INDUCTOR 10uH
L204 1-408-117-00 INDUCTOR 10uH
L301 1-456-094-11 TRANSFORMER, BIAS OSCILLATION
L302 1-408-105-31 INDUCTOR 1uH
< CABLE HOLDER >
PN401 1-784-584-11 HOLDER, CABLE (2.5mm PITCH) 7P
< RESISTOR >
0PR501 1-220-890-11 METAL 0.22 10% 3W
< TRANSISTOR >
Q301 6-550-333-01 TRANSISTOR 2SC5343GL
Q302 6-550-333-01 TRANSISTOR 2SC5343GL
Q303 6-550-333-01 TRANSISTOR 2SC5343GL
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q305 8-729-045-62 TRANSISTOR 2SK2158-T2B
Q306 8-729-028-83 TRANSISTOR DTA124EUA-T106
Q307 8-729-045-62 TRANSISTOR 2SK2158-T2B
Q308 8-729-045-62 TRANSISTOR 2SK2158-T2B
Q309 8-729-216-22 TRANSISTOR 2SA1162-G
Q310 8-729-216-22 TRANSISTOR 2SA1162-G
Q311 8-729-028-83 TRANSISTOR DTA124EUA-T106
Q312 1-801-806-11 TRANSISTOR DTC144EKA
Q313 1-801-806-11 TRANSISTOR DTC144EKA
MAIN
Ver. 1.6
