Ref. No. Part No. Description Remarks
50
HCD-GP5
CN802 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-991-33 DIODE 1SS133T-77
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
< COIL >
0 L801 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< TRANSFORMER >
0 PT802 1-439-781-11 TRANSFORMER, POWER (US, CND)
0 PT802 1-439-772-11 TRANSFORMER, POWER
(E51, HK, SP, TW, AUS)
0 PT802 1-443-041-11 TRANSFORMER, POWER (AEP, UK, KR)
< RESISTOR >
0 R803 1-219-776-11 CARBON 2.2M 10% 1/2W
(US, CND)
< RELAY >
0 RY801 1-755-276-11 RELAY, POWER
< SWITCH >
0 SW801 1-786-404-11 SELECTOR, VOLTAGE (SWS-2201)
(VOLTAGE SELECTOR) (E51)
************************************************************
MISCELLANEOUS
***************
2 1-827-731-11 WIRE (FLAT TYPE) (11 CORE)
(EXCEPT AEP, UK, KR)
2 1-828-984-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK, KR)
3 1-693-619-11 TUNER (FM/AM) (AEP, UK, KR)
3 1-693-620-11 TUNER (FM/AM) (E51, HK, SP, TW, AUS)
3 1-693-624-11 TUNER (FM/AM) (US, CND)
0 5 1-555-795-00 CORD, POWER (EXCEPT US, CND, TW, KR)
0 5 1-769-079-22 CORD, POWER (KR)
0 5 1-783-532-11 CORD, POWER (US, CND, TW)
6 1-827-714-11 WIRE (FLAT TYPE) (21 CORE)
72 1-829-747-11 WIRE (FLAT TYPE) (26 CORE)
73 1-796-351-51 MECHANISM, SIGNAL CASSETTE
173 1-757-055-11 WIRE, PARALLEL (FFC) (16 CORE)
0 601 A-4735-357-A OPTICAL PICK-UP ASSY (KSM213DHAP/ZRP1)
M901 A-4735-337-A MOTOR (LD) ASSY (TRAY)
0 PT801 1-443-032-11 TRANSFORMER, POWER (US, CND)
0 PT801 1-443-033-11 TRANSFORMER, POWER (AEP, UK)
0 PT801 1-443-034-11 TRANSFORMER, POWER (HK, SP, AUS)
0 PT801 1-443-035-11 TRANSFORMER, POWER (E51, TW)
0 PT801 1-443-036-11 TRANSFORMER, POWER (KR)
`
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
TRANSFORMER
Ver. 1.6
