Sony HCD-GRX50 - Page 64

– 89 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R343 1-249-417-11 CARBON 1K 5% 1/4W
R351 1-249-435-11 CARBON 33K 5% 1/4W
R352 1-249-421-11 CARBON 2.2K 5% 1/4W
R353 1-247-807-31 CARBON 100 5% 1/4W
R354 1-247-807-31 CARBON 100 5% 1/4W
R355 1-249-421-11 CARBON 2.2K 5% 1/4W
R356 1-249-428-11 CARBON 8.2K 5% 1/4W
R357 1-249-428-11 CARBON 8.2K 5% 1/4W
R358 1-249-425-11 CARBON 4.7K 5% 1/4W
R359 1-249-435-11 CARBON 33K 5% 1/4W
R391 1-247-807-31 CARBON 100 5% 1/4W
R392 1-247-807-31 CARBON 100 5% 1/4W
R393 1-249-435-11 CARBON 33K 5% 1/4W
R394 1-249-435-11 CARBON 33K 5% 1/4W
R401 1-260-076-11 CARBON 10 5% 1/2W
(R770/RXD7: AEP)
R402 1-260-076-11 CARBON 10 5% 1/2W
(R770/RXD7: AEP)
R406 1-249-437-11 CARBON 47K 5% 1/4W
(EXCEPT RXD7: CND)
R407 1-249-437-11 CARBON 47K 5% 1/4W
(EXCEPT RXD7: CND)
R408 1-249-425-11 CARBON 4.7K 5% 1/4W
(EXCEPT RXD7: CND)
R409 1-249-441-11 CARBON 100K 5% 1/4W
(EXCEPT RXD7: CND)
R410 1-249-421-11 CARBON 2.2K 5% 1/4W
(EXCEPT RXD7: CND)
! R411 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(R770/RXD7: AEP)
! R411 1-216-456-00 METAL OXIDE 820 5% 2W F
(RXD7: CND)
! R411 1-215-894-11 METAL OXIDE 2.2K 5% 2W F
(GRX50)
R413 1-249-402-11 CARBON 56 5% 1/4W
R414 1-249-417-11 CARBON 1K 5% 1/4W
R415 1-249-429-11 CARBON 10K 5% 1/4W
R416 1-249-437-11 CARBON 47K 5% 1/4W
R417 1-249-417-11 CARBON 1K 5% 1/4W
R421 1-260-087-81 CARBON 100 5% 1/2W
(RXD7: CND)
R421 1-260-089-11 CARBON 150 5% 1/2W
(EXCEPT RXD7: CND)
R422 1-260-087-81 CARBON 100 5% 1/2W
(RXD7: CND)
R422 1-260-089-11 CARBON 150 5% 1/2W
(EXCEPT RXD7: CND)
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R434 1-249-433-11 CARBON 22K 5% 1/4W
R435 1-249-435-11 CARBON 33K 5% 1/4W
R437 1-249-429-11 CARBON 10K 5% 1/4W
R438 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W
R440 1-249-433-11 CARBON 22K 5% 1/4W
R441 1-249-435-11 CARBON 33K 5% 1/4W
R443 1-249-417-11 CARBON 1K 5% 1/4W
R451 1-260-076-11 CARBON 10 5% 1/2W
(R770/RXD7: AEP)
R452 1-260-076-11 CARBON 10 5% 1/2W
(R770/RXD7: AEP)
R471 1-260-087-81 CARBON 100 5% 1/2W
(RXD7: CND)
R471 1-260-089-11 CARBON 150 5% 1/2W
(EXCEPT RXD7: CND)
R472 1-260-087-81 CARBON 100 5% 1/2W
(RXD7: CND)
R472 1-260-089-11 CARBON 150 5% 1/2W
(EXCEPT RXD7: CND)
R473 1-249-402-11 CARBON 56 5% 1/4W
R474 1-249-417-11 CARBON 1K 5% 1/4W
R481 1-260-087-81 CARBON 100 5% 1/2W
(RXD7: CND)
R481 1-260-089-11 CARBON 150 5% 1/2W
(EXCEPT RXD7: CND)
R482 1-260-087-81 CARBON 100 5% 1/2W
(RXD7: CND)
R482 1-260-089-11 CARBON 150 5% 1/2W
(EXCEPT RXD7: CND)
R483 1-260-087-81 CARBON 100 5% 1/2W
(RXD7: CND)
R483 1-260-089-11 CARBON 150 5% 1/2W
(EXCEPT RXD7: CND)
R484 1-260-087-81 CARBON 100 5% 1/2W
(RXD7: CND)
R484 1-260-089-11 CARBON 150 5% 1/2W
(EXCEPT RXD7: CND)
R501 1-249-413-11 CARBON 470 5% 1/4W
R502 1-249-425-11 CARBON 4.7K 5% 1/4W
R503 1-249-437-11 CARBON 47K 5% 1/4W
R504 1-249-437-11 CARBON 47K 5% 1/4W
R505 1-249-429-11 CARBON 10K 5% 1/4W
R508 1-249-421-11 CARBON 2.2K 5% 1/4W
R509 1-249-441-11 CARBON 100K 5% 1/4W
R510 1-249-409-11 CARBON 220 5% 1/4W
R521 1-249-437-11 CARBON 47K 5% 1/4W
R522 1-249-419-11 CARBON 1.5K 5% 1/4W
R523 1-249-427-11 CARBON 6.8K 5% 1/4W
(R770/RXD7: AEP)
R523 1-249-433-11 CARBON 22K 5% 1/4W
(GRX50: E2, MX, AR)
R523 1-249-437-11 CARBON 47K 5% 1/4W
(GRX50: EA3, EA4, TH, KR, AUS)
R524 1-247-843-11 CARBON 3.3K 5% 1/4W
(GRX50: EA4, TH, KR, AUS)
R524 1-249-435-11 CARBON 33K 5% 1/4W
(GRX50: EA3)
R524 1-249-437-11 CARBON 47K 5% 1/4W
(GRX50: E2, MX, AR/R770/RXD7: AEP)
R527 1-249-429-11 CARBON 10K 5% 1/4W
R536 1-249-429-11 CARBON 10K 5% 1/4W
R550 1-247-843-11 CARBON 3.3K 5% 1/4W
R551 1-249-429-11 CARBON 10K 5% 1/4W
R567 1-247-807-31 CARBON 100 5% 1/4W
R568 1-249-429-11 CARBON 10K 5% 1/4W
R569 1-249-429-11 CARBON 10K 5% 1/4W
R570 1-249-429-11 CARBON 10K 5% 1/4W
R571 1-249-429-11 CARBON 10K 5% 1/4W
R577 1-249-429-11 CARBON 10K 5% 1/4W
R610 1-247-891-00 CARBON 330K 5% 1/4W
MAIN
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
