Sony HCD-GRX70 - Page 63

– 85 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C662 1-162-306-11 CERAMIC 0.01uF 20% 16V
C664 1-104-665-11 ELECT 100uF 20% 10V
C698 1-162-306-11 CERAMIC 0.01uF 20% 16V
C699 1-104-665-11 ELECT 100uF 20% 10V
C801 1-126-963-11 ELECT 4.7uF 20% 50V
(GRX70/GRX70J)
C801 1-128-581-11 ELECT 4.7uF 20% 100V
(RXD80)
C802 1-162-290-31 CERAMIC 470PF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-104-665-11 ELECT 100uF 20% 10V
C807 1-136-495-11 FILM 0.068uF 5% 50V
C808 1-136-495-11 FILM 0.068uF 5% 50V
C809 1-128-560-11 ELECT 22uF 20% 100V
C810 1-128-578-11 ELECT 1uF 20% 100V
C811 1-162-306-11 CERAMIC 0.01uF 20% 16V
C812 1-162-306-11 CERAMIC 0.01uF 20% 16V
C841 1-127-811-11 ELECT 3300uF 20% 50V
(GRX70/GRX70J)
C842 1-127-752-11 ELECT 3300uF 20% 63V
(RXD80)
C842 1-127-814-11 ELECT 3300uF 20% 80V
(GRX70/GRX70J)
C843 1-136-165-00 FILM 0.1uF 5% 50V
(GRX70/GRX70J)
C844 1-130-777-00 FILM 0.1uF 10% 100V
C851 1-126-963-11 ELECT 4.7uF 20% 50V
(GRX70/GRX70J)
C851 1-128-581-11 ELECT 4.7uF 20% 100V
(RXD80)
C852 1-162-290-31 CERAMIC 470PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-104-665-11 ELECT 100uF 20% 10V
C857 1-136-495-11 FILM 0.068uF 5% 50V
C858 1-136-495-11 FILM 0.068uF 5% 50V
C859 1-128-560-11 ELECT 22uF 20% 100V
C881 1-126-967-11 ELECT 47uF 20% 50V
C891 1-127-811-11 ELECT 3300uF 20% 50V
(GRX70/GRX70J)
C892 1-127-752-11 ELECT 3300uF 20% 63V
(RXD80)
C892 1-127-814-11 ELECT 3300uF 20% 80V
(GRX70/GRX70J)
C893 1-136-165-00 FILM 0.1uF 5% 50V
(GRX70/GRX70J)
C894 1-130-777-00 FILM 0.1uF 10% 100V
C901 1-136-165-00 FILM 0.1uF 5% 50V
C902 1-126-936-11 ELECT 3300uF 20% 16V
(RXD80)
C902 1-126-937-11 ELECT 4700uF 20% 16V
(GRX70/GRX70J)
C903 1-126-933-11 ELECT 100uF 20% 16V
C904 1-104-664-11 ELECT 47uF 20% 16V
C905 1-104-665-11 ELECT 100uF 20% 10V
C906 1-136-165-00 FILM 0.1uF 5% 50V
C907 1-128-548-11 ELECT 4700uF 20% 25V
C909 1-126-964-11 ELECT 10uF 20% 50V
C910 1-104-665-11 ELECT 100uF 20% 10V
C911 1-126-964-11 ELECT 10uF 20% 50V
C912 1-126-926-11 ELECT 1000uF 20% 10V
C913 1-126-964-11 ELECT 10uF 20% 50V
C914 1-126-767-11 ELECT 1000uF 20% 16V
C915 1-104-664-11 ELECT 47uF 20% 16V
C916 1-162-306-11 CERAMIC 0.01uF 20% 16V
C917 1-126-933-11 ELECT 100uF 20% 16V
C951 1-136-165-00 FILM 0.1uF 5% 50V
C952 1-126-768-11 ELECT 2200uF 20% 16V
C953 1-126-933-11 ELECT 100uF 20% 16V
C955 1-104-665-11 ELECT 100uF 20% 10V
C956 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
CN303 1-784-776-11 CONNECTOR, FFC 15P
CN304 1-784-778-11 CONNECTOR, FFC 17P
CN371 1-784-774-11 CONNECTOR, FFC 13P
(GRX70: E2, TH, MX, AR/RXD80)
CN371 1-784-776-11 CONNECTOR, FFC 15P
(GRX70: E3, SP, TW, AUS/GRX70J)
CN391 1-784-741-11 CONNECTOR, FFC 19P
CN392 1-785-334-11 PIN, CONNECTOR (LIGHT ANGLE) 8P
CN393 1-785-335-11 PIN, CONNECTOR (LIGHT ANGLE) 9P
* CN403 1-564-518-11 PLUG, CONNECTOR 3P
CN501 1-784-784-11 CONNECTOR, FFC 23P
< DIODE >
D141 8-719-911-19 DIODE 1SS119
D191 8-719-911-19 DIODE 1SS119
D331 8-719-911-19 DIODE 1SS119
D333 8-719-911-19 DIODE 1SS119
D334 8-719-911-19 DIODE 1SS119
D335 8-719-911-19 DIODE 1SS119
D401 8-719-911-19 DIODE 1SS119
D403 8-719-911-19 DIODE 1SS119
D405 8-719-024-99 DIODE 11ES2-NTA2B
D406 8-719-024-99 DIODE 11ES2-NTA2B
D407 8-719-024-99 DIODE 11ES2-NTA2B
D411 8-719-911-19 DIODE 1SS119
D501 8-719-024-99 DIODE 11ES2-NTA2B
D502 8-719-911-19 DIODE 1SS119
D503 8-719-911-19 DIODE 1SS119
D504 8-719-911-19 DIODE 1SS119
D505 8-719-911-19 DIODE 1SS119
D506 8-719-911-19 DIODE 1SS119
D509 8-719-911-19 DIODE 1SS119
D607 8-719-911-19 DIODE 1SS119
D644 8-719-911-19 DIODE 1SS119
D801 8-719-911-19 DIODE 1SS119
D802 8-719-160-64 DIODE RD16F-B1
D803 8-719-911-19 DIODE 1SS119
D831 8-719-302-38 DIODE RBV-602-01
D832 8-719-302-38 DIODE RBV-602-01 (GRX70/GRX70J)
D851 8-719-911-19 DIODE 1SS119
D852 8-719-160-64 DIODE RD16F-B1
D881 8-719-911-19 DIODE 1SS119
D901 8-719-024-99 DIODE 11ES2-NTA2B
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
MAIN
