Sony HCD-GRX70 - Sensor Board

– 92 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R703 1-249-429-11 CARBON 10K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-429-11 CARBON 10K 5% 1/4W
R710 1-249-401-11 CARBON 47 5% 1/4W
(GRX70J: EA3)
R711 1-249-433-11 CARBON 22K 5% 1/4W
(GRX70J: EA3)
R712 1-249-433-11 CARBON 22K 5% 1/4W
(GRX70J: EA3)
R713 1-249-433-11 CARBON 22K 5% 1/4W
(GRX70J: EA3)
R714 1-249-437-11 CARBON 47K 5% 1/4W
(GRX70J: EA3)
R715 1-249-433-11 CARBON 22K 5% 1/4W
(GRX70J: EA3)
R716 1-249-431-11 CARBON 15K 5% 1/4W
(GRX70J: EA3)
R717 1-249-433-11 CARBON 22K 5% 1/4W
(GRX70J: EA3)
R718 1-249-433-11 CARBON 22K 5% 1/4W
(GRX70J: EA3)
R719 1-247-881-00 CARBON 120K 5% 1/4W
(GRX70J: EA3)
R721 1-249-429-11 CARBON 10K 5% 1/4W
R722 1-249-417-11 CARBON 1K 5% 1/4W
R723 1-249-441-11 CARBON 100K 5% 1/4W
R724 1-249-417-11 CARBON 1K 5% 1/4W
R725 1-249-433-11 CARBON 22K 5% 1/4W
R726 1-249-429-11 CARBON 10K 5% 1/4W
R727 1-249-431-11 CARBON 15K 5% 1/4W
(GRX70J: EA3)
R728 1-247-885-00 CARBON 180K 5% 1/4W
R729 1-247-807-31 CARBON 100 5% 1/4W
R731 1-249-440-11 CARBON 82K 5% 1/4W
R732 1-249-437-11 CARBON 47K 5% 1/4W
R733 1-249-440-11 CARBON 82K 5% 1/4W
R734 1-249-417-11 CARBON 1K 5% 1/4W
R735 1-249-420-11 CARBON 1.8K 5% 1/4W
R741 1-249-421-11 CARBON 2.2K 5% 1/4W
R742 1-249-421-11 CARBON 2.2K 5% 1/4W
R743 1-249-421-11 CARBON 2.2K 5% 1/4W
< VARIABLE RESISTOR >
RV711 1-225-739-11 RES, VAR 50K (ECHO LEVEL) (GRX70J: EA3)
RV712 1-225-739-11 RES, VAR 50K (MIC LEVEL)
< SWITCH >
S601 1-473-534-11 ENCODER, ROTARY (JOG DIAL)
S602 1-473-392-11 ENCODER, ROTARY (VOLUME)
S611 1-762-875-21 SWITCH, KEYBOARD (SYNC BASS)
S612 1-762-875-21 SWITCH, KEYBOARD (SYNC EQ)
S613 1-762-875-21 SWITCH, KEYBOARD (KARAOKE PON/MPX)
S614 1-762-875-21 SWITCH, KEYBOARD (NON-STOP)
S615 1-762-875-21 SWITCH, KEYBOARD (SURROUND)
S616 1-762-875-21 SWITCH, KEYBOARD (DBFB)
S617 1-762-875-21 SWITCH, KEYBOARD (ENTER/NEXT)
S618 1-762-875-21 SWITCH, KEYBOARD (+ ))
S619 1-762-875-21 SWITCH, KEYBOARD (- 0)
S620 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S621 1-762-875-21 SWITCH, KEYBOARD (FLASH)
S622 1-762-875-21 SWITCH, KEYBOARD
(REPEAT STEREO/MONO)
S623 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE, DOLBY NR)
S624 1-762-875-21 SWITCH, KEYBOARD
(EDIT, DIRECTION, TUNER MEMORY)
S625 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S626 1-762-875-21 SWITCH, KEYBOARD (HI-DUB)
S627 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S628 1-762-875-21 SWITCH, KEYBOARD (LOOP)
S629 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S630 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM ANALYZER)
S638 1-762-875-21 SWITCH, KEYBOARD (TIMER SELECT)
S639 1-762-875-21 SWITCH, KEYBOARD (P FILE MEMORY)
S640 1-762-875-21 SWITCH, KEYBOARD (GEQ CONTROL)
S641 1-762-875-21 SWITCH, KEYBOARD (FILE SELECT)
S642 1-762-875-21 SWITCH, KEYBOARD (EFFECT)
S643 1-762-875-21 SWITCH, KEYBOARD (TUNER BAND)
S644 1-762-875-21 SWITCH, KEYBOARD (^ CD)
S645 1-762-875-21 SWITCH, KEYBOARD (p)
S646 1-762-875-21 SWITCH, KEYBOARD (( TAPE B)
S647 1-762-875-21 SWITCH, KEYBOARD (9 TAPE B)
S648 1-762-875-21 SWITCH, KEYBOARD (( TAPE A)
S649 1-762-875-21 SWITCH, KEYBOARD (9 TAPE A)
S650 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S651 1-762-875-21 SWITCH, KEYBOARD (CLOCK TIMER SET)
< VIBRATOR >
X601 1-781-312-11 VIBRATOR, CERAMIC (12.5MHz)
************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< PHOTO INTERRUPTER >
IC702 8-749-924-18 PHOTO INTERRUPTER RPI-1391
< PHOTO REFLECTOR >
IC703 8-749-924-30 PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W
R702 1-249-407-11 CARBON 150 5% 1/4W
************************************************************
* A-4417-729-A SUB TRANS BOARD, COMPLETE (RXD80)
**************************
< CAPACITOR >
C11 1-126-768-11 ELECT 2200uF 20% 16V
C12 1-164-159-11 CERAMIC 0.1uF 50V
C13 1-126-933-11 ELECT 100uF 20% 16V
C14 1-126-968-11 ELECT 100uF 20% 50V
C15 1-164-159-11 CERAMIC 0.1uF 50V
C16 1-126-948-11 ELECT 100uF 20% 35V
! C21 1-113-925-11 CERAMIC 0.01uF 20% 250V
PANEL SENSOR SUB TRANS
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
