Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< CONNECTOR >
CN11 1-564-321-00 PIN, CONNECTOR 2P
* CN12 1-564-321-21 PIN, CONNECTOR 2P
CN13 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE) 7P
< DIODE >
D11 8-719-911-19 DIODE 1SS119
D12 8-719-210-21 DIODE 11EQS04
D13 8-719-210-21 DIODE 11EQS04
D14 8-719-210-21 DIODE 11EQS04
D15 8-719-210-21 DIODE 11EQS04
D16 8-719-911-19 DIODE 1SS119
D17 8-719-024-99 DIODE 11ES2-NTA2B
D18 8-719-024-99 DIODE 11ES2-NTA2B
D19 8-719-024-99 DIODE 11ES2-NTA2B
D20 8-719-024-99 DIODE 11ES2-NTA2B
D21 8-719-986-60 DIODE HZS27-3LTA
D22 8-719-109-63 DIODE RD3.0ESB2
D23 8-719-911-19 DIODE 1SS119
< IC >
IC11 8-759-450-47 IC BA05T
< TRANSISTOR >
Q11 8-729-119-78 TRANSISTOR 2SC403SP-51
Q12 8-729-040-19 TRANSISTOR RT1N137L-TP
Q13 8-729-118-01 TRANSISTOR 2SB1116
Q14 8-729-040-19 TRANSISTOR RT1N137L-TP
Q15 8-729-040-19 TRANSISTOR RT1N137L-TP
Q16 8-729-900-63 TRANSISTOR DTA124ES
Q17 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R11 1-249-429-11 CARBON 10K 5% 1/4W
R12 1-249-441-11 CARBON 100K 5% 1/4W
R13 1-249-417-11 CARBON 1K 5% 1/4W
R15 1-249-429-11 CARBON 10K 5% 1/4W
R16 1-247-807-31 CARBON 100 5% 1/4W
R17 1-247-807-31 CARBON 100 5% 1/4W
R18 1-247-807-31 CARBON 100 5% 1/4W
R19 1-249-427-11 CARBON 6.8K 5% 1/4W
R20 1-249-429-11 CARBON 10K 5% 1/4W
R23 1-249-427-11 CARBON 6.8K 5% 1/4W
< RELAY >
! RY11 1-755-276-11 RELAY, POWER
< TRANSFORMER >
! T11 1-433-587-11 TRANSFORMER, POWER
************************************************************
* 1-672-369-11 TRANS BOARD
************************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
! C952 1-162-306-11 CERAMIC 0.01uF 20% 16V
(GRX70J)
C971 1-128-563-11 ELECT 100uF 20% 100V
(GRX70/GRX70J)
C972 1-126-960-11 ELECT 1uF 20% 50V
(GRX70/GRX70J)
C973 1-126-948-11 ELECT 100uF 20% 35V
(GRX70/GRX70J)
< CONNECTOR >
CN951 1-564-321-00 PIN, CONNECTOR 2P (GRX70/GRX70J)
* CN952 1-564-527-11 PLUG, CONNECTOR 12P (GRX70/GRX70J)
* CN952 1-564-524-11 PLUG, CONNECTOR 9P (RXD80)
CN953 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
(GRX70/GRX70J)
< DIODE >
D971 8-719-024-99 DIODE 11ES2-NTA2B (GRX70/GRX70J)
D972 8-719-986-60 DIODE HZS27-3LTA (GRX70/GRX70J)
D973 8-719-109-63 DIODE RD3.0ESB2 (GRX70/GRX70J)
< FUSE >
! F951 1-532-506-31 FUSE T6.3AL/250V
(GRX70: E2, E3, SP, TW, AR/GRX70J)
! F951 1-533-310-11 FUSE, GLASS TUBE 6.3A/125V (RXD80)
! F961 1-532-505-31 FUSE T5AL/250V (GRX70/GRX70J)
! F962 1-532-505-31 FUSE T5AL/250V (GRX70/GRX70J)
! F963 1-532-506-31 FUSE T6.3AL/250V (GRX70/GRX70J)
! F964 1-532-506-31 FUSE T6.3AL/250V (GRX70/GRX70J)
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932 (TP)
(GRX70/GRX70J)
< RESISTOR >
! R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(RXD80)
! R951 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
(GRX70/GRX70J)
! R952 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
(RXD80)
! R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(GRX70/GRX70J)
! R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R961 1-202-725-00 SOLID 3.3M 10% 1/2W
(RXD80)
!R971 1-216-456-00 METAL OXIDE 820 5% 2W F
(GRX70/GRX70J)
R972 1-249-429-11 CARBON 10K 5% 1/4W
(GRX70/GRX70J)
R973 1-249-429-11 CARBON 10K 5% 1/4W
(GRX70/GRX70J)
R974 1-247-807-31 CARBON 100 5% 1/4W
(GRX70/GRX70J)
R975 1-247-807-31 CARBON 100 5% 1/4W
(GRX70/GRX70J)
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
SUB TRANS TRANS
