– 57 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
R116 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R117 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R118 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R119 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R120 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R121 1-216-114-00 METAL GLAZE 510K 5% 1/10W
R122 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R123 1-216-099-00 METAL CHIP 120K 5% 1/10W
R124 1-216-091-00 METAL CHIP 56K 5% 1/10W
R125 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R126 1-216-063-91 METAL GLAZE 3.9K 5% 1/10W
R127 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R128 1-216-105-91 METAL GLAZE 220K 5% 1/10W
R129 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R130 1-216-079-00 METAL CHIP 18K 5% 1/10W
R131 1-216-079-00 METAL CHIP 18K 5% 1/10W
R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R133 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R134 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R135 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R138 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R139 1-216-033-00 METAL CHIP 220 5% 1/10W
R140 1-216-081-00 METAL CHIP 22K 5% 1/10W
R141 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R142 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R143 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R144 1-216-073-00 METAL CHIP 10K 5% 1/10W
R145 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R146 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R147 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R148 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R149 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R150 1-216-037-00 METAL CHIP 330 5% 1/10W
R151 1-216-037-00 METAL CHIP 330 5% 1/10W
R152 1-216-037-00 METAL CHIP 330 5% 1/10W
R153 1-216-082-00 METAL GLAZE 24K 5% 1/10W
R154 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R156 1-216-085-00 METAL CHIP 33K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-241-396-11 RES, ADJ, METAL GLAZE 22K(FOCUS BIAS)
RV102 1-241-396-11 RES, ADJ, METAL GLAZE 22K(FOCUS GAIN)
RV103 1-241-396-11 RES, ADJ, METAL GLAZE 22K(TRACKING GAIN)
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT SW)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
* 1-659-146-11 CD PANEL BOARD
***************
< DIODE >
D551 8-719-056-13 LED SML79423C-TP15 (DISC 3)
D552 8-719-056-13 LED SML79423C-TP15 (DISC 3)
D553 8-719-056-13 LED SML79423C-TP15 (DISC 2)
D554 8-719-056-13 LED SML79423C-TP15 (DISC 2)
D555 8-719-056-13 LED SML79423C-TP15 (DISC 1)
D556 8-719-056-13 LED SML79423C-TP15 (DISC 1)
D583 8-719-056-13 LED SML79423C-TP15 (fl )
< RESISTOR >
R501 1-249-401-11 CARBON 47 5% 1/4W
R502 1-249-403-11 CARBON 68 5% 1/4W
R503 1-247-807-31 CARBON 100 5% 1/4W
R504 1-249-407-11 CARBON 150 5% 1/4W
R505 1-249-407-11 CARBON 150 5% 1/4W
R506 1-247-815-91 CARBON 220 5% 1/4W
R507 1-249-411-11 CARBON 330 5% 1/4W
R508 1-249-413-11 CARBON 470 5% 1/4W
R551 1-249-401-11 CARBON 68 5% 1/4W
R552 1-249-401-11 CARBON 68 5% 1/4W
R553 1-249-401-11 CARBON 68 5% 1/4W
R554 1-249-401-11 CARBON 68 5% 1/4W
R555 1-249-401-11 CARBON 68 5% 1/4W
R556 1-249-401-11 CARBON 68 5% 1/4W
R583 1-249-401-11 CARBON 68 5% 1/4W
R584 1-249-401-11 CARBON 68 5% 1/4W
< SWITCH >
S500 1-762-196-21 SWITCH, TACT (POWER)
S501 1-762-196-21 SWITCH, TACT (LOOP)
S502 1-762-196-21 SWITCH, TACT (DISC SKIP/EX CHANGE)
S503 1-762-196-21 SWITCH, TACT (DISC 1)
S504 1-762-196-21 SWITCH, TACT (DISC 2)
S505 1-762-196-21 SWITCH, TACT (DISC 3)
S506 1-762-196-21 SWITCH, TACT (§ OPEN/CLOSE)
S507 1-762-196-21 SWITCH, TACT (p)
S508 1-762-196-21 SWITCH, TACT (fl)
************************************************************
* 1-658-575-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
CD PANELBD CONNECTOR
