– 58 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W
************************************************************
* 1-659-147-11 H.P BOARD
**********
< CAPACITOR >
C519 1-162-294-31 CERAMIC 0.001uF 10% 50V
C520 1-162-294-31 CERAMIC 0.001uF 10% 50V
C521 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
CN503 1-506-468-11 PIN, CONNECTOR 3P
< JACK >
J501 1-770-226-11 JACK (LARGE TYPE) (PHONES)
************************************************************
* A-4389-126-A MAIN BOARD, COMPLETE (H331:AR,AUS,E,MX)
* A-4389-127-A MAIN BOARD, COMPLETE (H331:US,Canadian)
* A-4389-144-A MAIN BOARD, COMPLETE (H331D)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C201 1-124-925-11 ELECT 2.2uF 20% 100V
C202 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C203 1-126-925-11 ELECT 470uF 20% 10V
C204 1-162-282-31 CERAMIC 100PF 10% 50V
C205 1-162-282-31 CERAMIC 100PF 10% 50V
C251 1-124-925-11 ELECT 2.2uF 20% 100V
C252 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C300 1-162-282-31 CERAMIC 100PF 10% 50V
C301 1-162-290-31 CERAMIC 470PF 10% 50V
C302 1-136-157-00 FILM 0.022uF 5% 50V
C303 1-126-964-11 ELECT 10uF 20% 50V
C304 1-162-292-31 CERAMIC 680PF 10% 50V
C310 1-162-282-31 CERAMIC 100PF 10% 50V
C311 1-162-289-31 CERAMIC 390PF 10% 50V
C312 1-136-157-00 FILM 0.022uF 5% 50V
C313 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-934-11 ELECT 220uF 20% 16V
C321 1-130-479-00 MYLAR 0.0047uF 5% 50V
C322 1-124-903-11 ELECT 1uF 20% 50V
C323 1-126-963-11 ELECT 4.7uF 20% 50V
C324 1-136-165-00 FILM 0.1uF 5% 50V
C326 1-124-903-11 ELECT 1uF 20% 50V
C327 1-124-902-00 ELECT 0.47uF 20% 50V
C328 1-126-963-11 ELECT 4.7uF 20% 50V
C329 1-162-291-31 CERAMIC 560PF 10% 50V
C330 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C331 1-107-599-11 CERAMIC 27PF 5% 500V
C332 1-101-890-00 CERAMIC 75PF 5% 50V
C333 1-162-288-31 CERAMIC 330PF 10% 50V
C334 1-102-973-00 CERAMIC 100PF 5% 50V
C335 1-162-286-21 CERAMIC 220PF 10% 50V
C336 1-162-286-21 CERAMIC 220PF 10% 50V
C340 1-124-925-11 ELECT 2.2uF 20% 100V
C351 1-130-478-00 MYLAR 0.0039uF 5% 50V
C352 1-130-478-00 MYLAR 0.0039uF 5% 50V
C353 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C354 1-130-482-00 MYLAR 0.0082uF 5% 50V
C355 1-124-925-11 ELECT 2.2uF 20% 100V
C356 1-130-487-00 MYLAR 0.022uF 5% 50V
C357 1-126-934-11 ELECT 220uF 20% 16V
C360 1-130-848-00 FILM 0.0082uF 5% 100V
C381 1-126-933-11 ELECT 100uF 20% 16V
C382 1-126-933-11 ELECT 100uF 20% 16V
C383 1-126-933-11 ELECT 100uF 20% 16V
C384 1-126-933-11 ELECT 100uF 20% 16V
C385 1-126-964-11 ELECT 10uF 20% 50V
C386 1-126-964-11 ELECT 10uF 20% 50V
C388 1-126-934-11 ELECT 220uF 20% 16V
C389 1-162-306-11 CERAMIC 0.01uF 30% 16V
C390 1-162-282-31 CERAMIC 100PF 10% 50V
C391 1-126-934-11 ELECT 220uF 20% 16V
C392 1-126-934-11 ELECT 220uF 20% 16V
C400 1-162-282-31 CERAMIC 100PF 10% 50V
C401 1-162-290-31 CERAMIC 470PF 10% 50V
C402 1-136-157-00 FILM 0.022uF 5% 50V
C403 1-126-964-11 ELECT 10uF 20% 50V
C404 1-162-292-31 CERAMIC 680PF 10% 50V
C410 1-162-282-31 CERAMIC 100PF 10% 50V
C411 1-162-289-31 CERAMIC 390PF 10% 50V
C412 1-136-157-00 FILM 0.022uF 5% 50V
C413 1-126-964-11 ELECT 10uF 20% 50V
C415 1-126-934-11 ELECT 220uF 20% 16V
C421 1-130-479-00 MYLAR 0.0047uF 5% 50V
C422 1-124-903-11 ELECT 1uF 20% 50V
C423 1-126-963-11 ELECT 4.7uF 20% 50V
C424 1-136-165-00 FILM 0.1uF 5% 50V
C426 1-124-903-11 ELECT 1uF 20% 50V
C427 1-124-902-00 ELECT 0.47uF 20% 50V
C428 1-126-963-11 ELECT 4.7uF 20% 50V
C429 1-162-291-31 CERAMIC 560PF 10% 50V
C430 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C431 1-107-599-11 CERAMIC 27PF 5% 500V
