– 63 –
R922 1-249-429-11 CARBON 10K 5% 1/4W
R923 1-247-903-00 CARBON 1M 5% 1/4W
R938 1-247-807-31 CARBON 100 5% 1/4W
R940 1-249-429-11 CARBON 10K 5% 1/4W
R941 1-249-429-11 CARBON 10K 5% 1/4W
R942 1-249-429-11 CARBON 10K 5% 1/4W
R951 1-249-425-11 CARBON 4.7K 5% 1/4W
R952 1-249-425-11 CARBON 4.7K 5% 1/4W
R954 1-249-431-11 CARBON 15K 5% 1/4W
R955 1-249-441-11 CARBON 100K 5% 1/4W
R956 1-247-892-11 CARBON 360K 5% 1/4W
R957 1-249-440-11 CARBON 82K 5% 1/4W
R958 1-247-863-91 CARBON 22K 5% 1/4W
R959 1-249-419-11 CARBON 1.5K 5% 1/4W
R960 1-249-429-11 CARBON 10K 5% 1/4W
R961 1-249-421-11 CARBON 2.2K 5% 1/4W
R962 1-249-441-11 CARBON 100K 5% 1/4W
R963 1-249-429-11 CARBON 10K 5% 1/4W
R964 1-249-437-11 CARBON 47K 5% 1/4W
R965 1-249-431-11 CARBON 15K 5% 1/4W
R970 1-247-903-00 CARBON 1M 5% 1/4W
R973 1-247-903-00 CARBON 1M 5% 1/4W
R1001 1-249-421-11 CARBON 2.2K 5% 1/4W
R1002 1-247-815-91 CARBON 220 5% 1/4W
R1011 1-249-421-11 CARBON 2.2K 5% 1/4W
R1023 1-249-417-11 CARBON 1K 5% 1/4W
R1201 1-249-417-11 CARBON 1K 5% 1/4W
R1202 1-249-437-11 CARBON 47K 5% 1/4W
R1203 1-249-414-11 CARBON 560 5% 1/4W
R1204 1-249-437-11 CARBON 47K 5% 1/4W
R1205 1-260-103-11 CARBON 2.2K 5% 1/2W
R1207 1-260-103-11 CARBON 2.2K 5% 1/2W
! R1210 1-208-602-11 WIREWOUND 0.22 10% 2W F
R1211 1-249-417-11 CARBON 1K 5% 1/4W
R1212 1-249-431-11 CARBON 15K 5% 1/4W
R1213 1-249-441-11 CARBON 100K 5% 1/4W
R1214 1-260-099-11 CARBON 1K 5% 1/2W
R1217 1-260-099-11 CARBON 1K 5% 1/2W
R1218 1-260-076-11 CARBON 10 5% 1/2W
R1222 1-249-407-11 CARBON 150 5% 1/4W
R1223 1-249-407-11 CARBON 150 5% 1/4W
R1224 1-249-429-11 CARBON 10K 5% 1/4W
R1225 1-249-429-11 CARBON 10K 5% 1/4W
! R1226 1-216-452-11 METAL OXIDE 180 5% 2W F
R1227 1-249-429-11 CARBON 10K 5% 1/4W
R1228 1-247-891-00 CARBON 330K 5% 1/4W
R1229 1-249-429-11 CARBON 10K 5% 1/4W
R1230 1-249-429-11 CARBON 10K 5% 1/4W
R1231 1-249-417-11 CARBON 1K 5% 1/4W
R1233 1-249-425-11 CARBON 4.7K 5% 1/4W
R1234 1-249-425-11 CARBON 4.7K 5% 1/4W
R1235 1-249-435-11 CARBON 33K 5% 1/4W
R1236 1-249-441-11 CARBON 100K 5% 1/4W
R1237 1-249-429-11 CARBON 10K 5% 1/4W
R1240 1-249-438-11 CARBON 56K 5% 1/4W
R1241 1-247-791-91 CARBON 22 5% 1/4W
R1242 1-249-429-11 CARBON 10K 5% 1/4W
R1243 1-249-383-11 CARBON 1.5 5% 1/6W
R1245 1-247-863-91 CARBON 22K 5% 1/4W
R1250 1-249-421-11 CARBON 2.2K 5% 1/4W
R1251 1-249-417-11 CARBON 1K 5% 1/4W
R1252 1-249-437-11 CARBON 47K 5% 1/4W
R1253 1-249-414-11 CARBON 560 5% 1/4W
R1254 1-249-437-11 CARBON 47K 5% 1/4W
R1255 1-260-103-11 CARBON 2.2K 5% 1/2W
R1257 1-260-103-11 CARBON 2.2K 5% 1/2W
! R1260 1-208-602-11 WIREWOUND 0.22 10% 2W F
R1261 1-249-417-11 CARBON 1K 5% 1/4W
R1262 1-249-431-11 CARBON 15K 5% 1/4W
R1263 1-249-441-11 CARBON 100K 5% 1/4W
R1268 1-260-076-11 CARBON 10 5% 1/2W
R1272 1-249-407-11 CARBON 150 5% 1/4W
R1273 1-249-407-11 CARBON 150 5% 1/4W
R1290 1-249-437-11 CARBON 47K 5% 1/4W
R1295 1-247-863-91 CARBON 22K 5% 1/4W
R1303 1-249-425-11 CARBON 4.7K 5% 1/4W
R1304 1-249-425-11 CARBON 4.7K 5% 1/4W
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K(PB LEVEL L:DECK A)
RV302 1-238-600-11 RES, ADJ, CARBON 10K(PB LEVEL L:DECK B)
RV303 1-238-600-11 RES, ADJ, CARBON 10K(REC LEVEL L:DECK B)
RV304 1-238-603-11 RES, ADJ, CARBON 100K (BIAS L)
RV380 1-238-599-11 RES, ADJ, CARBON 4.7K (SPEED)
RV401 1-238-600-11 RES, ADJ, CARBON 10K(PB LEVEL R:DECK A)
RV402 1-238-600-11 RES, ADJ, CARBON 10K(PB LEVEL R:DECK B)
RV403 1-238-600-11 RES, ADJ, CARBON 10K(REC LEVEL R:DECK B)
RV404 1-238-603-11 RES, ADJ, CARBON 100K (BIAS R)
< RELAY >
RY1201 1-515-921-11 RELAY (12V)
< TRANSFORMER >
T350 1-433-349-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM1201 1-537-925-41 TERMINAL BOARD (SPEAKER)
< VIBRATOR >
X701 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
X702 1-567-098-41 VIBRATOR, CRYSTAL (32MHz)
************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN
