– 64 –
* 1-658-578-11 MOTOR (SLIDE) BOARD
********************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 30% 16V
C804 1-162-306-11 CERAMIC 0.01uF 30% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-010-43 DIODE UZ-5.6BSC-TP
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN SW)
************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-010-23 DIODE UZ-3.6BSB
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
************************************************************
* A-4389-137-A PANEL BOARD, COMPLETE
**********************
* 4-932-810-11 CUSHION (FL)
* 4-978-168-01 HOLDER, FL TUBE
< CAPACITOR >
C501 1-162-282-31 CERAMIC 100PF 10% 50V
C502 1-162-282-31 CERAMIC 100PF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-162-282-31 CERAMIC 100PF 10% 50V
C505 1-162-282-31 CERAMIC 100PF 10% 50V
C506 1-162-282-31 CERAMIC 100PF 10% 50V
C507 1-162-282-31 CERAMIC 100PF 10% 50V
C508 1-162-282-31 CERAMIC 100PF 10% 50V
C509 1-162-282-31 CERAMIC 100PF 10% 50V
C510 1-162-282-31 CERAMIC 100PF 10% 50V
C511 1-162-282-31 CERAMIC 100PF 10% 50V
C512 1-162-282-31 CERAMIC 100PF 10% 50V
C513 1-162-294-31 CERAMIC 0.001uF 10% 50V
C514 1-126-967-11 ELECT 47uF 20% 50V
C515 1-162-306-11 CERAMIC 0.01uF 30% 16V
C516 1-124-584-00 ELECT 100uF 20% 10V
C517 1-162-306-11 CERAMIC 0.01uF 30% 16V
C522 1-162-306-11 CERAMIC 0.01uF 30% 16V
C523 1-162-306-11 CERAMIC 0.01uF 30% 16V
C524 1-162-294-31 CERAMIC 0.001uF 10% 50V
C525 1-124-903-11 ELECT 1uF 20% 50V
C526 1-162-294-31 CERAMIC 0.001uF 10% 50V
C527 1-124-903-11 ELECT 1uF 20% 50V
< CONNECTOR >
* CN501 1-568-858-11 SOCKET, CONNECTOR 15P
< DIODE >
D548 8-719-033-06 LED SEL5920A (CLIP A)
D549 8-719-033-06 LED SEL5920A (CLIP B)
D550 8-719-812-44 LED TLO124 (ENTER/NEXT)
D560 8-719-010-40 DIODE UZ-5.6BS
D578 8-719-058-03 LED SEL5423E (TIMER/BAND)
D580 8-719-812-44 LED TLO124 (EFFECT ON/OFF)
D581 8-719-033-06 LED SEL5920A (GROOVE)
D582 8-719-033-06 LED SEL5920A (CLIP C)
D605 8-719-033-06 LED SEL5920A (CD)
D615 8-719-033-06 LED SEL5920A (TUNER)
D625 8-719-033-06 LED SEL5920A (TIMER)
< INDICATOR TUBE >
FL501 1-517-489-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC501 8-759-375-45 IC ASD042
IC502 8-759-332-18 IC GP1U27XB
< TRANSISTOR >
Q501 8-729-119-76 TRANSISTOR 2SA1175-HFE
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
PANEL
MOTOR (TURN)MOTOR (SLIDE)
