Sony HCD-M100 - Printed Wiring Board - Rear Amp Section

HCD-M100/M300AV
47
47
6-23. PRINTED WIRING BOARD – REAR AMP SECTION – (HCD-M300AV ONLY) • See page 27 for Circuit Boards Location.
11
CENTER SPEAKER
(11)
REAR SP TERM BOARD
REAR SPEAKER
R
L
4
1
1
A
B
C
D
E
234
1-677-248-
REAR AMP BOARD
TO
FRONT AMP
BOARD
CN701
O
(Page34)
11
(11)
115
E
EE
E
4
E
7
E
TO
TRANS BOARD
CN993
D
(Page41)
TO
MAIN BOARD
CN841B
G
(Page34)
4
3
1
1
L842
L841
Ref. No. Location
D771 B-1
D841 B-3
D842 B-3
D882 C-2
D883 C-1
D961 D-4
IC831 A-4
Q291 B-1
Q292 B-2
Q771 C-1
Q772 C-1
Q841 B-4
Q842 B-3
• Semiconductor
Location
