Sony HCD-M100 - 1 General; Font Panel

5
SECTION 1
GENERAL
FRONT PANEL
1 @/1 button
2 STANDBY indicator
3 MEMO INPUT button
4 MEMO SCAN button
5 MEMO SEARCH button
6 TAPE A h button and indicator
7 CD 7 button and indicator
8 TAPE A H button and indicator
9 Display window
0 x (STOP) button
qa TAPE B h button and indicator
qs TUNER/BAND button
qd TAPE B H button and indicator
qf CHECK button
qg CLEAR button
qh DELETE button
qj GROOVE button and indicator
qk FUNCTION button
ql DSP button and indicator
w; DBFB button
wa CONTINUE/STEREO/MONO button
ws ENTER button
wd PROGRAM/TUNER MEMORY button
wf SHUFFLE/DIRECTION button
wg + M > button
wh m .– button
wj SELECTOR dial
wk PHONES jack
wl FILE SELECT button
e; VOLUME knob
ea X PAUSE button and indicator
es CD SYNCHRO button
ed z REC button
ef CD PLUS ONE button
eg TIMER SELECT button and indicator
eh CLOCK TIMER SET button
ej DISPLAY button
ek PROLOGIC button and indicator
(HCD-M300AV only)
1
ef
eg
eh
ej
ek
2
3
4
5
67 8 90 qaqsqd qfqgqh
qj
qk
w;
wa
ws
wd
wf
wg
wh
wj
wk
wle;eaesed
ql
Photo: HCD-M300AV
