SECTION 8
ELECTRICAL PARTS LIST
* A-4699-869-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C102 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C103 1-164-489-11 CERAMIC CHIP 0.22uF 10.00% 16V
C104 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C105 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C106 1-110-501-11 CERAMIC CHIP 0.33uF 10.00% 16V
C107 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C108 1-164-492-11 CERAMIC CHIP 0.15uF 10.00% 16V
C109 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C110 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C111 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C112 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C113 1-164-492-11 CERAMIC CHIP 0.15uF 10.00% 16V
C114 1-164-492-11 CERAMIC CHIP 0.15uF 10.00% 16V
C115 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C116 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C117 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C118 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C119 1-164-489-11 CERAMIC CHIP 0.22uF 10.00% 16V
C120 1-124-234-00 ELECT 22uF 20% 16V
C121 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C122 1-126-963-11 ELECT 4.7uF 20.00% 50V
C123 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C124 1-104-396-11 ELECT 10uF 20.00% 16V
C125 1-126-177-11 ELECT 100uF 20% 10V
C126 1-126-177-11 ELECT 100uF 20% 10V
C127 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C128 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C129 1-110-501-11 CERAMIC CHIP 0.33uF 10.00% 16V
C130 1-104-665-11 ELECT 100uF 20.00% 10V
C131 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C132 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C133 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C141 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C142 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C151 1-107-725-11 CERAMIC CHIP 0.1uF 10.00% 16V
C152 1-107-725-11 CERAMIC CHIP 0.1uF 10.00% 16V
C153 1-107-725-11 CERAMIC CHIP 0.1uF 10.00% 16V
C154 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C155 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C156 1-163-085-00 CERAMIC CHIP 2PF 50V
C157 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C158 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C159 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
C160 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C161 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C162 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C163 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C164 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C165 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C166 1-104-665-11 ELECT 100uF 20.00% 10V
C167 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C171 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C172 1-126-177-11 ELECT 100uF 20% 10V
C173 1-124-589-11 ELECT 47uF 20% 16V
C174 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C175 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C181 1-104-664-11 ELECT 47uF 20.00% 16V
C182 1-104-664-11 ELECT 47uF 20.00% 16V
C183 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C184 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
< CONNECTOR >
CN101 1-770-173-11 CONNECTOR, FFC/FPC 16P
CN102 1-691-894-21 SOCKET, CONNECTOR 16P
* CN103 1-568-852-11 SOCKET, CONNECTOR 9P
< DIODE >
D151 8-719-991-33 DIODE 1SS133T-77
< IC >
IC101 8-759-449-64 IC LA9240M
IC102 8-759-449-65 IC LC78622E
IC103 8-759-449-66 IC LA6541
IC104 8-759-428-57 IC LC89170M
< JUMPER RESISTOR >
JW1 1-216-295-91 SHORT 0
JW2 1-216-295-91 SHORT 0
JW4 1-216-295-91 SHORT 0
JW5 1-216-295-91 SHORT 0
JW6 1-216-295-91 SHORT 0
JW7 1-216-295-91 SHORT 0
JW8 1-216-295-91 SHORT 0
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
BD
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
