– 13 –
NOTE FOR INSTALLATION
• SLIDER COMPLETE ASS’Y
Install the part A of lever (head up)
to pass over the slider complete ass’y.
part A
OK
NG
Take care not to damage
the detective switch.
slider ass’y
SLIDER COMPLETE ASS’Y
claw
claw
45°
3
Set the shaft of gear (LB) to be at the
position in the figure.
2
retainer (gear)
4
Remove the slider complete ass’y
in the direction of arrow with putting
out of two claws.
1
special screw
(M 1.7
×
1.4)
