– 98 –
S916 1-554-303-21 SWITCH, TACTILE
(PLAY MODE, TUNING MODE)
************************************************************
* A-4403-410-A POWER AMP BOARD, COMPLETE
(AEP, UK, G, AED)
* A-4403-417-A POWER AMP BOARD, COMPLETE (MY, SP, HK)
* A-4407-385-A POWER AMP BOARD, COMPLETE (CND)
***************************
< CAPACITOR >
C1201 1-126-963-11 ELECT 4.7uF 20% 50V
C1202 1-162-288-31 CERAMIC 330PF 10% 50V
C1203 1-162-286-31 CERAMIC 220PF 10% 50V
C1204 1-126-967-11 ELECT 47uF 20% 50V
C1205 1-126-967-11 ELECT 47uF 20% 50V
C1206 1-126-948-11 ELECT 100uF 20% 35V
C1207 1-136-165-00 FILM 0.1uF 5% 50V
C1208 1-126-965-11 ELECT 22uF 20% 50V
C1210 1-136-163-00 FILM 0.068uF 5% 50V
C1211 1-136-163-00 FILM 0.068uF 5% 50V
C1220 1-126-924-11 ELECT 330uF 20% 10V
C1251 1-126-963-11 ELECT 4.7uF 20% 50V
C1252 1-162-288-31 CERAMIC 330PF 10% 50V
C1253 1-162-286-31 CERAMIC 220PF 10% 50V
C1254 1-126-967-11 ELECT 47uF 20% 50V
C1255 1-126-967-11 ELECT 47uF 20% 50V
C1256 1-126-948-11 ELECT 100uF 20% 35V
C1257 1-136-165-00 FILM 0.1uF 5% 50V
C1260 1-136-163-00 FILM 0.068uF 5% 50V
C1261 1-136-163-00 FILM 0.068uF 5% 50V
C1301 1-126-042-11 ELECT 3300uF 20% 35V
C1302 1-126-042-11 ELECT 3300uF 20% 35V
C1303 1-136-165-00 FILM 0.1uF 5% 50V
C1304 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
* CN1202 1-565-485-11 CONNECTOR, BOARD TO BOARD 9P
< DIODE >
D1201 8-719-911-19 DIODE 1SS119
D1202 8-719-911-19 DIODE 1SS119
D1203 8-719-911-19 DIODE 1SS119
D1213 8-719-911-19 DIODE 1SS119
D1251 8-719-911-19 DIODE 1SS119
D1263 8-719-911-19 DIODE 1SS119
D1300 8-719-025-03 DIODE RBA-402-SL
< IC >
IC1201 8-749-920-13 IC STK-4132MK2
< TRANSISTOR >
Q1201 8-729-620-05 TRANSISTOR 2SC2603-EF
Q1202 8-729-900-80 TRANSISTOR DTC114ES
Q1231 8-729-422-73 TRANSISTOR UN4212
Q1232 8-729-620-05 TRANSISTOR 2SC2603-EF
Q1251 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
R1201 1-249-417-11 CARBON 1K 5% 1/4W
R1202 1-249-437-11 CARBON 47K 5% 1/4W
R1203 1-249-417-11 CARBON 1K 5% 1/4W
R1204 1-249-437-11 CARBON 47K 5% 1/4W
R1205 1-260-103-11 CARBON 2.2K 5% 1/2W
R1207 1-260-103-11 CARBON 2.2K 5% 1/2W
! R1209 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R1210 1-217-151-00 RES, METAL PLATE 0.22 2W F
R1211 1-249-417-11 CARBON 1K 5% 1/4W
R1212 1-249-431-11 CARBON 15K 5% 1/4W
R1214 1-260-099-11 CARBON 1K 5% 1/2W
R1217 1-260-099-11 CARBON 1K 5% 1/2W
R1218 1-249-397-11 CARBON 22 5% 1/4W
R1219 1-249-397-11 CARBON 22 5% 1/4W
R1225 1-249-397-11 CARBON 22 5% 1/4W
R1226 1-249-429-11 CARBON 10K 5% 1/4W
R1227 1-247-854-11 CARBON 9.1K 5% 1/4W
(EXCEPT CND)
R1227 1-249-429-11 CARBON 10K 5% 1/4W
(CND)
R1228 1-247-880-11 CARBON 110K 5% 1/4W
(AEP, UK, G, AED)
R1228 1-249-441-11 CARBON 100K 5% 1/4W
(CND, MY, SP, HK)
R1229 1-249-429-11 CARBON 10K 5% 1/4W
R1231 1-247-807-31 CARBON 100 5% 1/4W
R1232 1-249-429-11 CARBON 10K 5% 1/4W
R1233 1-249-429-11 CARBON 10K 5% 1/4W
! R1243 1-217-637-00 FUSIBLE 1 5% 1/4W F
R1251 1-249-417-11 CARBON 1K 5% 1/4W
R1252 1-249-437-11 CARBON 47K 5% 1/4W
R1253 1-249-417-11 CARBON 1K 5% 1/4W
R1254 1-249-437-11 CARBON 47K 5% 1/4W
R1255 1-260-103-11 CARBON 2.2K 5% 1/2W
R1257 1-260-103-11 CARBON 2.2K 5% 1/2W
! R1259 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R1260 1-217-151-00 RES, METAL PLATE 0.22 2W F
R1261 1-249-417-11 CARBON 1K 5% 1/4W
R1262 1-249-431-11 CARBON 15K 5% 1/4W
R1268 1-249-397-11 CARBON 22 5% 1/4W
R1269 1-249-397-11 CARBON 22 5% 1/4W
R1271 1-249-431-11 CARBON 15K 5% 1/4W
R1272 1-249-431-11 CARBON 15K 5% 1/4W
R1273 1-249-413-11 CARBON 470 5% 1/4W
< THERMISTOR >
THP12301-807-796-11 THERMISTOR
************************************************************
* 1-666-905-11 ST TERMINAL BOARD
******************
< CONNECTOR >
CN744 1-568-834-11 SOCKET, CONNECTOR 15P
CN745 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
************************************************************
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
POWER AMP ST TERMINAL
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
