– 99 –
* 1-667-719-11 SW BOARD
*********
< CONNECTOR >
CN601 1-770-697-11 CONNECTOR, FFC/FPC 14P
CN602 1-778-638-21 PIN, CONNECTOR (PC BOARD) 2P
CN603 1-778-638-21 PIN, CONNECTOR (PC BOARD) 2P
< SWITCH >
S681 1-572-467-61 SWITCH, PUSH (1 KEY) (LIMIT IN)
S682 1-692-377-31 SWITCH, PUSH (1 KEY) (REFLECT)
S683 1-692-847-21 SWITCH, PUSH (1 KEY) (PROTECT)
S685 1-572-467-61 SWITCH, PUSH (1 KEY) (CHUCKING IN)
S686 1-762-621-21 SWITCH, PUSH (1 KEY) (PACK OUT)
S687 1-572-688-11 SWITCH, PUSH (1 KEY) (PB POSITION)
S688 1-762-621-21 SWITCH, PUSH (1 KEY) (REC POSITION)
************************************************************
* 1-666-904-11 TRANSFORMER BOARD
*******************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
CN1600 1-564-321-00 PIN, CONNECTOR 2P
* CN1601 1-564-518-11 PLUG, CONNECTOR 3P
CN1602 1-564-523-11 PLUG, CONNECTOR 8P
< FUSE >
! F1601 1-532-388-31 FUSE (T2AL/250V) (MY, SP, HK)
! F1603 1-532-504-31 FUSE (T4AL/250V) (EXCEPT CND)
! F1603 1-533-419-11 FUSE, GLASS CYLINDRICAL (4A/125V) (CND)
! F1605 1-532-504-31 FUSE (T4AL/250V) (EXCEPT CND)
! F1605 1-533-419-11 FUSE, GLASS CYLINDRICAL (4A/125V) (CND)
< RESISTOR >
! R1600 1-202-725-00 SOLID 3.3M 10% 1/2W F
(CND)
< SWITCH >
! S1600 1-762-753-11 SWITCH, VOLTAGE SELECTION
(VOLTAGE SELECTOR) (MY, SP, HK)
< THERMISTOR (POSITIVE) >
THP16001-801-696-11 THERMISTOR, POSITIVE
THP16011-801-696-11 THERMISTOR, POSITIVE
THP16021-801-671-11 THERMISTOR, POSITIVE
THP16031-801-671-11 THERMISTOR, POSITIVE
************************************************************
MISCELLANEOUS
**************
10 1-782-793-11 WIRE (FLAT TYPE) (23 CORE)
52 1-782-990-11 WIRE (FLAT TYPE) (19 CORE)
56 1-782-991-11 WIRE (FLAT TYPE) (15 CORE) (10 cm)
62 1-233-544-21 ENCAPSULATED COMPONENT (CND)
62 1-233-546-21 ENCAPSULATED COMPONENT (MY, SP, HK)
62 1-693-387-21 TUNER (FM/MW/LW) (AEP, UK, G, AED)
64 1-783-213-11 WIRE (FLAT TYPE) (15 CORE): BEND (10 cm)
! 68 1-569-008-11 ADAPTOR, CONVERSION 2P (MY, SP)
! 69 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
103 1-782-683-11 WIRE (FLAT TYPE) (14 CORE)
110 1-782-792-11 WIRE (FLAT TYPE) (25 CORE)
! 167 8-583-028-02 OPTICAL PICK-UP KMS-260A/J1N (for MD)
! 255 8-848-367-11 OPTICAL PICK-UP KSS-213B/K-N (for CD)
256 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
!CNP1601 1-751-520-11 CORD, POWER (CND)
!CNP1601 1-696-570-21 CORD, POWER (UK)
!CNP1601 1-769-744-11 CORD, POWER (EXCEPT CND, UK)
FAN901 1-698-997-11 FAN, DC
HR901 1-500-396-11 HEAD, OVER LIGHT (RF325-74A)
M101 X-4917-523-4 BASE (OUTSART) ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M901 A-4672-135-A MOTOR ASSY, SPINDLE
M902 A-4672-133-A MOTOR ASSY, SLED
M903 A-4608-362-A MOTOR (L) ASSY (LOADING) (CD)
M903 A-4672-134-A MOTOR ASSY, LOADING (MD)
! T1600 1-431-497-11 TRANSFORMER, POWER (AEP, UK, G, AED)
! T1600 1-431-498-11 TRANSFORMER, POWER (MY, SP, HK)
! T1600 1-431-756-11 TRANSFORMER, POWER (CND)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#4 7-685-871-01 SCREW +BVTT 3X6
#5 7-685-850-04 SCREW +BVTT 2X3 (S)
#6 7-685-851-04 SCREW +BVTT 2X4 (S)
#7 7-627-553-17 PRECISION SCREW +P 2X2 TYPE 3
#8 7-627-552-27 SCREW, PRECISION +P 1.7X2
#9 7-624-105-04 STOP RING 2.3, TYPE-E
#10 7-685-234-19 SCREW +KTP 2.6X8 TYPE2 NON-SLIT
#11 7-621-775-10 SCREW +B 2.6X4
#12 7-621-255-15 SCREW +P 2X3
#13 7-627-852-28 +P 1.7X3
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
TRANSFORMER
SW
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
