Sony HCD-NE5 - Circuit Board Waveforms

HCD-NE5
1818
4.4 Vp-p
22.8 µ s
4.5 Vp-
p
472 ns
4.5 Vp-p
59 ns
Approx.
800 mVp-p
90.4 Vp-p
11.9 µ s
12.0 Vp-p
12 µ s
•Waveforms
– CD Board –
1 IC101 yd (LRCK)
2 IC101 yh (BCK)
3 IC101 uj (XTAO)
4 IC101 ra (RFACO)
– MAIN Board –
qa IC301 4 (REC mode)
qs Q344 Collector (REC mode)
3.2 Vp-p
30.6 µ s
3.0 Vp-p
100 ns
– CONTROL Board –
wa IC801 qd (O-XT2)
ws IC801 qh (XOUT)
