Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
41
HCD-NE5
< VARIABLE RESISTOR >
RV801 1-418-632-11 ENCODER, ROTARY (12 TYPE) (VOLUME)
< SWITCH >
S801 1-771-410-21 SWITCH, TACTILE (x)
S802 1-771-410-21 SWITCH, TACTILE (TUNING – .m)
S803 1-771-410-21 SWITCH, TACTILE (TUNING + M>)
S804 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S805 1-771-410-21 SWITCH, TACTILE (BASS/TREBLE)
S806 1-771-410-21 SWITCH, TACTILE (DSGX)
S807 1-771-410-21 SWITCH, TACTILE (ALBUM –)
S808 1-771-410-21 SWITCH, TACTILE (ALBUM +)
S809 1-771-410-21 SWITCH, TACTILE (I/1)
S810 1-771-410-21 SWITCH, TACTILE (TAPE N)
S811 1-771-410-21 SWITCH, TACTILE (CD NX)
S812 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S813 1-771-410-21 SWITCH, TACTILE (CD SYNCHRO)
S814 1-771-410-21 SWITCH, TACTILE (REC PAUSE/START z)
S815 1-771-410-21 SWITCH, TACTILE
(PLAY MODE/TUNING MODE)
< VIBRATOR >
X801 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
X802 1-795-004-21 VIBRATOR, CERAMIC (10MHz)
************************************************************
HP BOARD
*********
< CAPACITOR >
C520 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C521 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C525 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C526 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB501 1-410-396-41 FERRITE 0.45uH
< JACK >
J301 1-815-325-11 JACK (PHONES)
< RESISTOR >
R525 1-249-407-11 CARBON 150 5% 1/4W
R526 1-249-407-11 CARBON 150 5% 1/4W
************************************************************
A-4750-256-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C102 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C103 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C104 1-126-947-11 ELECT 47uF 20% 35V
C106 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C107 1-126-961-11 ELECT 2.2uF 20% 50V
C108 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C109 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C110 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C111 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C112 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C113 1-126-957-11 ELECT 0.22uF 20% 50V
C114 1-126-959-11 ELECT 0.47uF 20% 50V
C115 1-130-497-00 MYLAR 0.15uF 5% 50V
C116 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C117 1-164-730-11 CERAMIC CHIP 0.0012uF 10% 50V
C118 1-164-373-11 CERAMIC CHIP 0.033uF 25V
C119 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C127 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C132 1-126-963-11 ELECT 4.7uF 20% 50V
C133 1-130-492-11 MYLAR 0.056uF 5% 50V
C134 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C136 1-126-964-11 ELECT 10uF 20% 50V
C137 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C201 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C202 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C203 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C204 1-126-947-11 ELECT 47uF 20% 35V
C206 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C207 1-126-961-11 ELECT 2.2uF 20% 50V
C208 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C209 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C210 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C211 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C212 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C213 1-126-957-11 ELECT 0.22uF 20% 50V
C214 1-126-959-11 ELECT 0.47uF 20% 50V
C215 1-130-497-00 MYLAR 0.15uF 5% 50V
C216 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C217 1-164-730-11 CERAMIC CHIP 0.0012uF 10% 50V
C218 1-164-373-11 CERAMIC CHIP 0.033uF 25V
C219 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C227 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C232 1-126-963-11 ELECT 4.7uF 20% 50V
C233 1-130-492-11 MYLAR 0.056uF 5% 50V
C234 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C236 1-126-964-11 ELECT 10uF 20% 50V
C237 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C301 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C302 1-126-923-91 ELECT 220uF 20% 10V
C305 1-126-923-91 ELECT 220uF 20% 10V
C309 1-126-767-11 ELECT 1000uF 20% 16V
C312 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C313 1-126-933-11 ELECT 100uF 20% 16V
C314 1-136-969-11 MYLAR 0.012uF 5% 100V
C319 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C320 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C324 1-126-934-11 ELECT 220uF 20% 16V
C326 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C327 1-126-947-11 ELECT 47uF 20% 35V
C328 1-126-933-11 ELECT 100uF 20% 16V
CONTROL HP MAIN
