Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
44
HCD-NE5
MAIN POWER
0 R361 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
R362 1-216-836-11 METAL CHIP 18K 5% 1/10W
R363 1-216-836-11 METAL CHIP 18K 5% 1/10W
R364 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R365 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R366 1-216-837-11 METAL CHIP 22K 5% 1/10W
R367 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R368 1-216-833-11 METAL CHIP 10K 5% 1/10W
R370 1-216-841-11 METAL CHIP 47K 5% 1/10W
R371 1-216-841-11 METAL CHIP 47K 5% 1/10W
R372 1-247-807-31 CARBON 100 5% 1/4W
R373 1-216-845-11 METAL CHIP 100K 5% 1/10W
R374 1-249-429-11 CARBON 10K 5% 1/4W
R387 1-216-833-11 METAL CHIP 10K 5% 1/10W
R388 (not supplied) CARBON 16.8 1/8W
R389 1-216-821-11 METAL CHIP 1K 5% 1/10W
R390 1-216-821-11 METAL CHIP 1K 5% 1/10W
R391 1-260-298-51 CARBON 3.3 5% 1/2W
R392 1-216-809-11 METAL CHIP 100 5% 1/10W
R393 1-249-393-11 CARBON 10 5% 1/4W
R394 1-216-833-11 METAL CHIP 10K 5% 1/10W
R395 1-216-845-11 METAL CHIP 100K 5% 1/10W
R396 1-216-837-11 METAL CHIP 22K 5% 1/10W
R397 1-216-833-11 METAL CHIP 10K 5% 1/10W
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
A-4750-254-A POWER BOARD, COMPLETE (AEP, UK)
A-4751-365-A POWER BOARD, COMPLETE (CND)
A-4753-096-A POWER MOUNTED PC BOARD (E, E51, SP)
A-4753-098-A POWER MOUNTED PC BOARD
(MX, TW, AR, KR, AUS)
************************
< CAPACITOR >
C904 1-128-553-91 ELECT 220uF 20% 63V
C905 1-161-055-00 CERAMIC 0.022uF 10% 25V
C906 1-161-055-00 CERAMIC 0.022uF 10% 25V
C907 1-161-055-00 CERAMIC 0.022uF 10% 25V
C908 1-161-055-00 CERAMIC 0.022uF 10% 25V
C909 1-161-055-00 CERAMIC 0.022uF 10% 25V
C910 1-161-055-00 CERAMIC 0.022uF 10% 25V
C911 1-161-055-00 CERAMIC 0.022uF 10% 25V
C912 1-161-055-00 CERAMIC 0.022uF 10% 25V
C913 1-126-943-11 ELECT 2200uF 20% 25V
< CONNECTOR >
* CN901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CN903 1-564-514-11 PLUG, CONNECTOR 11P
< DIODE >
D905 8-719-200-02 DIODE 10E-2
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-991-33 DIODE 1SS133T-77
D908 8-719-991-33 DIODE 1SS133T-77
D909 8-719-991-33 DIODE 1SS133T-77
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
D910 8-719-991-33 DIODE 1SS133T-77
D911 8-719-063-79 DIODE 1N4002B
D912 8-719-063-79 DIODE 1N4002B
D913 8-719-063-79 DIODE 1N4002B
D914 8-719-063-79 DIODE 1N4002B
D916 8-719-046-47 DIODE 1N5401TM
D917 8-719-046-47 DIODE 1N5401TM
D918 8-719-046-47 DIODE 1N5401TM
D919 8-719-046-47 DIODE 1N5401TM
D920 8-719-991-33 DIODE 1SS133T-77
D921 8-719-991-33 DIODE 1SS133T-77
D922 8-719-991-33 DIODE 1SS133T-77
D923 8-719-991-33 DIODE 1SS133T-77
< IC LINK >
0 F901 1-245-420-11 LINK, IC (3A)
< LINE FILTER >
0 LF901 1-402-663-11 TRANSFORMER, LINE FILTER (LFT) (AEP, UK)
0 LF901 1-469-636-11 FERRITE CORE (EXCEPT AEP, UK)
< RESISTOR >
R901 1-249-437-11 CARBON 47K 5% 1/4W
R902 1-249-437-11 CARBON 47K 5% 1/4W
0 R903 1-219-237-11 SOLID 3.3M 20% 1/2W
(CND)
R904 1-249-393-11 CARBON 10 5% 1/4W
R905 1-249-421-11 CARBON 2.2K 5% 1/4W
R906 1-249-421-11 CARBON 470 5% 1/4W
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER
< SWITCH >
0 S901 1-571-309-11 SWITCH (VOLTAGE SELECTOR) (E, E51, SP)
< TRANSFORMER >
0 T901 1-439-779-11 TRANSFORMER, POWER
************************************************************
MISCELLANEOUS
**************
0 5 1-696-848-12 CORD, POWER (AUS)
0 5 1-769-079-23 CORD, POWER (KR)
0 5 1-769-744-52 CORD, POWER (AEP, UK, E51)
0 5 1-769-744-52 CORD, POWER (SP)
0 5 1-783-531-22 CORD, POWER (CND)
0 5 1-783-941-12 CORD, POWER (AR)
0 5 1-827-226-11 CORD, POWER (E2, MX)
0 5 1-827-597-41 CORD, POWER (TW)
6 1-693-625-11 TUNER (FM/AM) (CND)
6 1-693-626-11 TUNER (FM/AM) (AEP, UK)
6 1-693-628-11 TUNER (FM/AM)
(E, E51, MX, SP, TW, AR, AUS)
6 1-693-629-11 TUNER (FM/AM) (KR)
52 1-829-770-11 WIRE (FLAT TYPE) (24 CORE)
Ver 1.1
