HCD-RV660D/RV990D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R9981 1-216-864-11 METAL CHIP 0 5% 1/10W
R9986 1-216-864-11 METAL CHIP 0 5% 1/10W
R9987 1-216-864-11 METAL CHIP 0 5% 1/10W
R9988 1-216-864-11 METAL CHIP 0 5% 1/10W
R9993 1-216-864-11 METAL CHIP 0 5% 1/10W
R9994 1-216-864-11 METAL CHIP 0 5% 1/10W
R9998 1-216-864-11 METAL CHIP 0 5% 1/10W
R9999 1-216-864-11 METAL CHIP 0 5% 1/10W
< CAPACITOR >
R1101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1303 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1304 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1801 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1802 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1803 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< NETWORK RESISTOR >
RB10 1-233-388-11 RES, CHIP NETWORK 68X4 (3216)
RB11 1-233-388-11 RES, CHIP NETWORK 68X4 (3216)
RB12 1-233-388-11 RES, CHIP NETWORK 68X4 (3216)
RB13 1-233-388-11 RES, CHIP NETWORK 68X4 (3216)
RB14 1-233-388-11 RES, CHIP NETWORK 68X4 (3216)
RB15 1-233-388-11 RES, CHIP NETWORK 68X4 (3216)
RB16 1-233-388-11 RES, CHIP NETWORK 68X4 (3216)
RB17 1-233-388-11 RES, CHIP NETWORK 68X4 (3216)
RB18 1-234-524-21 RES, CHIP NETWORK 33X4
RB19 1-234-524-21 RES, CHIP NETWORK 33X4
RB20 1-234-524-21 RES, CHIP NETWORK 33X4
RB21 1-234-524-21 RES, CHIP NETWORK 33X4
RB202 1-234-523-21 RES, CHIP NETWORK 0X4 (3216)
RB203 1-234-523-21 RES, CHIP NETWORK 0X4 (3216)
RB204 1-234-523-21 RES, CHIP NETWORK 0X4 (3216)
< VIBRATOR >
X901 1-781-945-21 VIBRATOR, CERAMIC (20MHz)
X902 1-795-630-11 VIBRATOR, CRYSTAL (27MHz)
*************************************************************
1-687-135-11 DRIVER BOARD
*************
< CAPACITOR >
C715 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-964-11 ELECT 10uF 20% 50V
C735 1-164-159-21 CERAMIC 0.1uF 50V
C736 1-164-159-21 CERAMIC 0.1uF 50V
C737 1-164-159-21 CERAMIC 0.1uF 50V
C741 1-162-306-11 CERAMIC 0.01uF 30% 16V
C751 1-162-306-11 CERAMIC 0.01uF 30% 16V
C752 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-785-338-11 PIN, CONNECTOR (LIGHT ANGLE) 12P
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P
< DIODE >
D701 8-719-921-42 DIODE MTZJ-5.1A
D711 8-719-109-69 DIODE RD3.6ES-B2
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-417-11 CARBON 1K 5% 1/4W
R712 1-249-425-11 CARBON 4.7K 5% 1/4W
R713 1-249-433-11 CARBON 22K 5% 1/4W
R721 1-249-425-11 CARBON 4.7K 5% 1/4W
R722 1-249-425-11 CARBON 4.7K 5% 1/4W
R723 1-249-425-11 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-249-417-11 CARBON 1K 5% 1/4W
R734 1-249-430-11 CARBON 12K 5% 1/4W
R735 1-247-807-31 CARBON 100 5% 1/4W
R751 1-249-425-11 CARBON 4.7K 5% 1/4W
*************************************************************
A-4733-296-A FRONT AMP BOARD, COMPLETE
(RV990D:EXCEPT TH)
A-4733-297-A FRONT AMP BOARD, COMPLETE
(RV660D:EXCEPT TH)
A-4747-995-A FRONT AMP BOARD, COMPLETE (RV990D:TH)
A-4748-003-A FRONT AMP BOARD, COMPLETE (RV660D:TH)
***************************
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-162-294-31 CERAMIC 0.001uF 10% 50V
C203 1-162-286-21 CERAMIC 220PF 10% 50V
C204 1-126-967-11 ELECT 47uF 20% 50V
(RV660D)
C204 1-126-968-11 ELECT 100uF 20% 50V
(RV990D)
C206 1-136-495-11 FILM 0.068uF 5% 50V
C207 1-136-495-11 FILM 0.068uF 5% 50V
C208 1-128-551-11 ELECT 22uF 20% 63V
C216 1-162-306-11 CERAMIC 0.01uF 30% 16V
C221 1-126-971-11 ELECT 470uF 20% 50V
C231 1-126-964-11 ELECT 10uF 20% 50V
C232 1-104-665-11 ELECT 100uF 20% 10V
C233 1-126-961-11 ELECT 2.2uF 20% 50V
C234 1-104-665-11 ELECT 100uF 20% 10V
C235 1-164-159-11 CERAMIC 0.1uF 50V
C251 1-126-964-11 ELECT 10uF 20% 50V
C252 1-162-294-31 CERAMIC 0.001uF 10% 50V
DRIVERDMB03 FRONT AMP
