71
HCD-RV660D/RV990D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C253 1-162-286-21 CERAMIC 220PF 10% 50V
C254 1-126-967-11 ELECT 47uF 20% 50V
(RV660D)
C254 1-126-968-11 ELECT 100uF 20% 50V
(RV990D)
C256 1-136-495-11 FILM 0.068uF 5% 50V
C257 1-136-495-11 FILM 0.068uF 5% 50V
C258 1-128-551-11 ELECT 22uF 20% 63V
C271 1-135-928-21 ELECT 2200uF 20% 63V
C272 1-135-928-21 ELECT 2200uF 20% 63V
C273 1-137-844-21 ELECT 2200uF 20% 42V
(RV990D)
C274 1-137-844-21 ELECT 2200uF 20% 42V
(RV990D)
C281 1-136-165-00 FILM 0.1uF 5% 50V
C282 1-136-165-00 FILM 0.1uF 5% 50V
C283 1-136-165-00 FILM 0.1uF 5% 50V
C284 1-136-165-00 FILM 0.1uF 5% 50V
C285 1-162-306-11 CERAMIC 0.01uF 30% 16V
C286 1-162-306-11 CERAMIC 0.01uF 30% 16V
C921 1-126-956-11 ELECT 0.1uF 20% 50V
C922 1-126-767-11 ELECT 1000uF 20% 16V
C923 1-126-956-11 ELECT 0.1uF 20% 50V
C924 1-126-767-11 ELECT 1000uF 20% 16V
C925 1-126-956-11 ELECT 0.1uF 20% 50V
C926 1-126-933-11 ELECT 100uF 20% 16V
C933 1-126-956-11 ELECT 0.1uF 20% 50V
C934 1-126-935-11 ELECT 470uF 20% 10V
C937 1-126-956-11 ELECT 0.1uF 20% 50V
C938 1-126-935-11 ELECT 470uF 20% 10V
< CONNECTOR >
CN201 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CN206 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
< DIODE >
D201 8-719-991-33 DIODE 1SS133T-77
D230 8-719-991-33 DIODE 1SS133T-77
D231 8-719-991-33 DIODE 1SS133T-77
D251 8-719-991-33 DIODE 1SS133T-77
D281 8-719-991-33 DIODE 1SS133T-77
D291 8-719-991-33 DIODE 1SS133T-77
< IC >
IC201 6-704-107-01 IC STK403-100
IC203 6-703-610-01 IC RT8H015C-T112-1
< COIL >
L281 1-422-009-13 COIL, AIR-CORE
L282 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q201 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q216 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q217 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q221 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q222 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q232 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q233 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q234 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q251 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q281 8-729-026-39 TRANSISTOR 2SA933AS-QT
Q282 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R201 1-249-417-11 CARBON 1K 5% 1/4W
R202 1-249-437-11 CARBON 47K 5% 1/4W
R203 1-249-407-11 CARBON 150 5% 1/4W
(RV990D)
R203 1-249-411-11 CARBON 330 5% 1/4W
(RV660D)
R204 1-249-437-11 CARBON 47K 5% 1/4W
0 R205 1-245-235-21 METAL 0.22 10% 2W F
0 R206 1-245-235-21 METAL 0.22 10% 2W F
R207 1-249-417-11 CARBON 1K 5% 1/4W
R208 1-249-431-11 CARBON 15K 5% 1/4W
R209 1-249-441-11 CARBON 100K 5% 1/4W
R210 1-260-076-11 CARBON 10 5% 1/2W F
0 R211 1-212-881-11 FUSIBLE 100 5% 1/4W F
R214 1-249-406-11 CARBON 120 5% 1/4W
R215 1-249-433-11 CARBON 22K 5% 1/4W
R216 1-249-441-11 CARBON 100K 5% 1/4W
R217 1-249-429-11 CARBON 10K 5% 1/4W
R218 1-249-429-11 CARBON 10K 5% 1/4W
0 R219 1-202-972-61 FUSIBLE 1 5% 1/4W F
0 R220 1-202-972-61 FUSIBLE 1 5% 1/4W F
R221 1-249-421-11 CARBON 2.2K 5% 1/4W
R222 1-249-433-11 CARBON 22K 5% 1/4W
R223 1-249-429-11 CARBON 10K 5% 1/4W
R224 1-249-429-11 CARBON 10K 5% 1/4W
R225 1-249-439-11 CARBON 68K 5% 1/4W
R226 1-249-426-11 CARBON 5.6K 5% 1/4W
R230 1-249-425-11 CARBON 4.7K 5% 1/4W
R231 1-249-425-11 CARBON 4.7K 5% 1/4W
R233 1-249-425-11 CARBON 4.7K 5% 1/4W
R239 1-249-437-11 CARBON 47K 5% 1/4W
R240 1-249-438-11 CARBON 56K 5% 1/4W
R251 1-249-417-11 CARBON 1K 5% 1/4W
R252 1-249-437-11 CARBON 47K 5% 1/4W
R253 1-249-407-11 CARBON 150 5% 1/4W
(RV990D)
R253 1-249-411-11 CARBON 330 5% 1/4W
(RV660D)
R254 1-249-437-11 CARBON 47K 5% 1/4W
0 R255 1-245-235-21 METAL 0.22 10% 2W F
0 R256 1-245-235-21 METAL 0.22 10% 2W F
R257 1-249-417-11 CARBON 1K 5% 1/4W
R258 1-249-431-11 CARBON 15K 5% 1/4W
R259 1-249-441-11 CARBON 100K 5% 1/4W
R260 1-260-076-11 CARBON 10 5% 1/2W F
0 R261 1-212-881-11 FUSIBLE 100 5% 1/4W F
R271 1-249-441-11 CARBON 100K 5% 1/4W
R272 1-249-441-11 CARBON 100K 5% 1/4W
R273 1-249-441-11 CARBON 100K 5% 1/4W
(RV990D)
FRONT AMP
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
To Next Page
