72
HCD-RV660D/RV990D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R274 1-249-441-11 CARBON 100K 5% 1/4W
(RV990D)
0 R280 1-215-892-11 METAL OXIDE 1K 5% 2W F
(RV990D)
0 R280 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
(RV660D)
R281 1-260-076-11 CARBON 10 5% 1/2W F
R282 1-260-076-11 CARBON 10 5% 1/2W F
R283 1-260-076-11 CARBON 10 5% 1/2W F
R284 1-260-076-11 CARBON 10 5% 1/2W F
R285 1-249-437-11 CARBON 47K 5% 1/4W
R286 1-249-437-11 CARBON 47K 5% 1/4W
R287 1-249-429-11 CARBON 10K 5% 1/4W
R288 1-249-437-11 CARBON 47K 5% 1/4W
R289 1-249-429-11 CARBON 10K 5% 1/4W
R290 1-249-429-11 CARBON 10K 5% 1/4W
R924 1-249-417-11 CARBON 1K 5% 1/4W
< RELAY >
RY281 1-515-920-11 RELAY (24V)
< THERMISTOR >
TH201 1-807-796-11 THERMISTOR
< TERMINAL BOARD >
TM201 1-694-677-12 TERMINAL BOARD (4P) (FRONT SPEAKER)
*************************************************************
A-4733-292-A JACK BOARD, COMPLETE (EXCEPT E51,MX,TH)
A-4733-293-A JACK BOARD, COMPLETE (E51,MX)
A-4747-994-A JACK BOARD, COMPLETE (TH)
********************
< CAPACITOR >
C501 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C502 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C503 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C504 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C507 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C508 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C509 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C510 1-115-868-11 ELECT 0.22uF 20% 50V
C511 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C512 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C513 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C514 1-115-867-11 ELECT 0.1uF 20% 50V
C515 1-115-872-11 ELECT 2.2uF 20% 50V
C516 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C517 1-162-955-11 CERAMIC CHIP 150PF 5% 50V
C518 1-115-872-11 ELECT 2.2uF 20% 50V
C519 1-126-791-11 ELECT 10uF 20% 16V
C520 1-126-786-11 ELECT 47uF 20% 16V
C521 1-126-786-11 ELECT 47uF 20% 16V
C522 1-115-871-11 ELECT 1uF 20% 50V
(EXCEPT E51,MX)
C523 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(EXCEPT E51,MX)
C524 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT E51,MX)
C525 1-136-495-11 FILM 0.068uF 5% 50V
(EXCEPT E51,MX)
C526 1-115-870-11 ELECT 0.47uF 20% 50V
(EXCEPT E51,MX)
C527 1-115-870-11 ELECT 0.47uF 20% 50V
(EXCEPT E51,MX)
C528 1-136-167-00 FILM 0.15uF 5% 50V
(EXCEPT E51,MX)
C529 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT E51,MX)
C530 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(EXCEPT E51,MX)
C531 1-136-495-11 FILM 0.068uF 5% 50V
(EXCEPT E51,MX)
C532 1-126-785-11 ELECT 47uF 20% 10V
(EXCEPT E51,MX)
C533 1-126-785-11 ELECT 47uF 20% 10V
(EXCEPT E51,MX)
C534 1-115-871-11 ELECT 1uF 20% 50V
(EXCEPT E51,MX)
C535 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(EXCEPT E51,MX)
C536 1-115-872-11 ELECT 2.2uF 20% 50V
(EXCEPT E51,MX)
< CONNECTOR >
CN501 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P
CN502 1-785-334-11 PIN, CONNECTOR (LIGHT ANGLE) 8P
* CN503 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-988-61 DIODE 1SS355TE-17
D503 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D506 8-719-988-61 DIODE 1SS355TE-17
D1201 8-719-069-54 DIODE UDZS-TE17-5.1B (EXCEPT E51,MX)
< GROUND TERMINAL BOARD >
EPT501 1-537-771-21 TERMINAL BOARD, GROUND
EPT502 1-537-771-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB505 1-469-869-21 INDUCTOR (EMI FERRITE)
< IC >
IC501 8-759-710-97 IC NJM4565M-D
IC502 8-759-496-41 IC M65850FP-E1 (EXCEPT E51,MX)
< JACK >
J501 1-764-592-11 JACK 3P (GAME INPUT VIDEO,AUDIO L/R)
J502 1-794-702-11 JACK, HEADPHONE (PHONES)
J503 1-770-226-11 JACK (LARGE TYPE) (MIC)
< RESISTOR >
R501 1-216-821-11 METAL CHIP 1K 5% 1/10W
R502 1-216-821-11 METAL CHIP 1K 5% 1/10W
R503 1-216-841-11 METAL CHIP 47K 5% 1/10W
JACKFRONT AMP
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
