Sony HCD-RV660D - Page 73

73
HCD-RV660D/RV990D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R504 1-216-841-11 METAL CHIP 47K 5% 1/10W
R505 1-216-833-11 METAL CHIP 10K 5% 1/10W
R506 1-216-833-11 METAL CHIP 10K 5% 1/10W
R507 1-216-821-11 METAL CHIP 1K 5% 1/10W
R508 1-216-835-11 METAL CHIP 15K 5% 1/10W
R509 1-216-821-11 METAL CHIP 1K 5% 1/10W
R510 1-216-837-11 METAL CHIP 22K 5% 1/10W
R511 1-216-809-11 METAL CHIP 100 5% 1/10W
R512 1-216-833-11 METAL CHIP 10K 5% 1/10W
R513 1-216-847-11 METAL CHIP 150K 5% 1/10W
R514 1-216-809-11 METAL CHIP 100 5% 1/10W
R515 1-216-845-11 METAL CHIP 100K 5% 1/10W
R516 1-216-813-11 METAL CHIP 220 5% 1/10W
R517 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R518 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R519 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT E51,MX)
R520 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT E51,MX)
R521 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT E51,MX)
R522 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EXCEPT E51,MX)
R523 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT E51,MX)
R524 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT E51,MX)
R525 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT E51,MX)
R526 1-216-846-11 METAL CHIP 120K 5% 1/10W
(EXCEPT E51,MX)
R527 1-216-814-11 METAL CHIP 270 5% 1/10W
(EXCEPT E51,MX)
R528 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EXCEPT E51,MX)
R529 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EXCEPT E51,MX)
R531 1-260-083-11 CARBON 47 5% 1/2W F
R532 1-260-083-11 CARBON 47 5% 1/2W F
< VARIABLE RESISTOR >
RV501 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
RV502 1-223-983-11 RES, VAR, CARBON 50K (ECHO LEVEL)
(EXCEPT E51,MX)
*************************************************************
1-688-365-12 LEAD PIN BOARD (RV660D)
**************
< CONNECTOR >
CN303 1-785-318-11 PIN, CONNECTOR (STRAIGHT) 6P (RV660D)
CN304 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE) 6P (RV660D)
*************************************************************
1-688-363-12 LED BOARD
**********
< DIODE >
D361 8-719-071-44 LED SELS5223C-TP15 (POWER STREAM)
D362 8-719-071-44 LED SELS5223C-TP15 (POWER STREAM)
D363 8-719-071-44 LED SELS5223C-TP15 (POWER STREAM)
D364 8-719-071-44 LED SELS5223C-TP15 (POWER STREAM)
D365 8-719-071-44 LED SELS5223C-TP15 (POWER STREAM)
D366 8-719-071-44 LED SELS5223C-TP15 (POWER STREAM)
*************************************************************
A-4733-086-A MAIN BOARD, COMPLETE (RV990D:PH,SP,MY)
A-4733-093-A MAIN BOARD, COMPLETE (RV990D:E3,E15)
A-4733-094-A MAIN BOARD, COMPLETE (RV990D:EA)
A-4733-095-A MAIN BOARD, COMPLETE (RV990D:AUS)
A-4733-097-A MAIN BOARD, COMPLETE (RV990D:E51,MX)
A-4733-101-A MAIN BOARD, COMPLETE (RV660D:PH,SP,MY)
A-4733-131-A MAIN BOARD, COMPLETE (RV660D:E3,E15)
A-4733-132-A MAIN BOARD, COMPLETE (RV660D:EA)
A-4733-136-A MAIN BOARD, COMPLETE (RV660D:E51)
A-4747-967-A MAIN BOARD, COMPLETE (RV990D:TH)
A-4747-972-A MAIN BOARD, COMPLETE (RV660D:TH)
A-4749-059-A MAIN BOARD, COMPLETE (RV660D:AUS)
*********************
< CAPACITOR >
C102 1-126-382-11 ELECT 100uF 20% 10V
C104 1-126-961-11 ELECT 2.2uF 20% 50V
C106 1-115-872-11 ELECT 2.2uF 20% 50V
C109 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C110 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C111 1-126-795-11 ELECT 10uF 20% 50V
C112 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C113 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C114 1-126-795-11 ELECT 10uF 20% 50V
C116 1-136-169-00 FILM 0.22uF 5% 50V
C117 1-136-169-00 FILM 0.22uF 5% 50V
C119 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C120 1-126-795-11 ELECT 10uF 20% 50V
C123 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C125 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C126 1-136-169-00 FILM 0.22uF 5% 50V
C127 1-126-795-11 ELECT 10uF 20% 50V
C128 1-126-964-11 ELECT 10uF 20% 50V
C129 1-126-961-11 ELECT 2.2uF 20% 50V
C130 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C131 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C132 1-126-964-11 ELECT 10uF 20% 50V
C133 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C134 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C135 1-126-933-11 ELECT 100uF 20% 16V
C136 1-216-864-11 METAL CHIP 0 5% 1/10W
C137 1-126-961-11 ELECT 2.2uF 20% 50V
C138 1-126-961-11 ELECT 2.2uF 20% 50V
C139 1-126-961-11 ELECT 2.2uF 20% 50V
C140 1-136-169-00 FILM 0.22uF 5% 50V
C141 1-115-872-11 ELECT 2.2uF 20% 50V
C142 1-126-795-11 ELECT 10uF 20% 50V
C143 1-126-964-11 ELECT 10uF 20% 50V
(RV990D)
C144 1-126-964-11 ELECT 10uF 20% 50V
C145 1-110-518-11 ELECT 10uF 20% 100V
C146 1-110-518-11 ELECT 10uF 20% 100V
C149 1-126-795-11 ELECT 10uF 20% 50V
JACK MAINLEAD PIN LED
