75
HCD-RV660D/RV990D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C629 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C630 1-126-947-11 ELECT 47uF 20% 16V
C631 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C632 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C633 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C635 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C636 1-136-155-00 FILM 0.015uF 5% 50V
C637 1-137-194-81 FILM 0.47uF 5% 50V
C638 1-106-375-12 MYLAR 0.022uF 5% 200V
C655 1-126-963-11 ELECT 4.7uF 20% 50V
C656 1-126-961-11 ELECT 2.2uF 20% 50V
C657 1-126-961-11 ELECT 2.2uF 20% 50V
C658 1-126-933-11 ELECT 100uF 20% 16V
C659 1-126-933-11 ELECT 100uF 20% 16V
C660 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C661 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C662 1-136-153-00 FILM 0.01uF 5% 50V
C663 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C664 1-126-964-11 ELECT 10uF 20% 50V
C665 1-126-947-11 ELECT 47uF 20% 16V
C713 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C714 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C715 1-126-964-11 ELECT 10uF 20% 50V
C719 1-126-963-11 ELECT 4.7uF 20% 50V
C723 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C724 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C726 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C734 1-136-153-00 FILM 0.01uF 5% 50V
C735 1-136-153-00 FILM 0.01uF 5% 50V
C738 1-119-939-51 ELECT 6800uF 20% 35V
C739 1-126-961-11 ELECT 2.2uF 20% 50V
C740 1-111-235-61 ELECT 10000uF 20% 25V
C752 1-136-153-00 FILM 0.01uF 5% 50V
C753 1-136-153-00 FILM 0.01uF 5% 50V
C772 1-107-701-11 ELECT 47uF 20% 16V
(RV990D)
C773 1-107-701-11 ELECT 47uF 20% 16V
(RV990D)
C774 1-107-701-11 ELECT 47uF 20% 16V
C775 1-107-701-11 ELECT 47uF 20% 16V
C791 1-126-963-11 ELECT 4.7uF 20% 50V
C808 1-126-964-11 ELECT 10uF 20% 50V
(RV990D)
C809 1-126-964-11 ELECT 10uF 20% 50V
(RV990D)
C810 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C811 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C813 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C814 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C815 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C816 1-126-935-11 ELECT 470uF 20% 6.3V
C817 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C821 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C862 1-126-935-11 ELECT 470uF 20% 6.3V
C863 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C897 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C898 1-126-964-11 ELECT 10uF 20% 50V
C899 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN101 1-779-275-11 CONNECTOR, FFC (LIF(NON-ZIF)) 7P
CN102 1-568-830-11 CONNECTOR, FFC 11P
CN301 1-779-281-11 CONNECTOR, FFC (LIF(NON-ZIF)) 13P
(RV660D)
CN301 1-779-293-11 CONNECTOR, FFC (LIF(NON-ZIF)) 25P
(RV990D)
CN543 1-785-324-11 PIN, CONNECTOR (STRAIGHT) 12P
* CN602 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CN603 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN605 1-784-774-11 CONNECTOR, FFC 13P
* CN704 1-564-518-11 PLUG, CONNECTOR 3P
CN705 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
CN706 1-568-828-11 CONNECTOR, FFC 9P
CN707 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
* CN801 1-568-450-11 HOUSING, CONNECTOR (PC BOARD) 4P
* CN901 1-564-709-11 PIN, CONNECTOR (SMALL TYPE) 7P (RV990D)
< DIODE >
D102 8-719-069-56 DIODE UDZS-TE17-6.2B
D111 8-719-988-61 DIODE 1SS355TE-17
D112 8-719-988-61 DIODE 1SS355TE-17
D113 8-719-988-61 DIODE 1SS355TE-17
D201 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-988-61 DIODE 1SS355TE-17
D609 8-719-988-61 DIODE 1SS355TE-17
D610 8-719-988-61 DIODE 1SS355TE-17
D611 8-719-988-61 DIODE 1SS355TE-17
D703 8-719-988-61 DIODE 1SS355TE-17
D704 8-719-988-61 DIODE 1SS355TE-17
D705 8-719-988-61 DIODE 1SS355TE-17
D706 8-719-988-61 DIODE 1SS355TE-17
D707 8-719-988-61 DIODE 1SS355TE-17
D708 8-719-988-61 DIODE 1SS355TE-17
D709 8-719-988-61 DIODE 1SS355TE-17
D710 8-719-988-61 DIODE 1SS355TE-17
D711 8-719-988-61 DIODE 1SS355TE-17
D712 8-719-988-61 DIODE 1SS355TE-17
D714 6-500-522-21 DIODE 10EDB40-TB3
D716 8-719-069-56 DIODE UDZS-TE17-6.2B
D717 8-719-069-56 DIODE UDZS-TE17-6.2B
D729 8-719-085-36 DIODE 11EQS04-TB5
D732 8-719-028-23 DIODE D3SBA20-4101
D733 8-719-028-23 DIODE D3SBA20-4101
D734 8-719-988-61 DIODE 1SS355TE-17
D735 8-719-988-61 DIODE 1SS355TE-17
D804 8-719-988-61 DIODE 1SS355TE-17
D809 8-719-988-61 DIODE 1SS355TE-17
D810 8-719-988-61 DIODE 1SS355TE-17 (RV990D)
D811 8-719-988-61 DIODE 1SS355TE-17
D812 8-719-988-61 DIODE 1SS355TE-17 (RV990D)
D813 8-719-988-61 DIODE 1SS355TE-17
D814 8-719-988-61 DIODE 1SS355TE-17
D815 8-719-988-61 DIODE 1SS355TE-17
< GROUND TERMINAL BOARD >
EPT701 1-537-771-21 TERMINAL BOARD, GROUND
MAIN
