76
HCD-RV660D/RV990D
Ref. No. Part No. Description Remark
< FERRITE BEAD >
FB561 1-500-445-21 FERRITE, EMI (SMD)
FB801 1-500-445-21 FERRITE, EMI (SMD)
< JUMPER RESISTOR >
FB862 1-216-864-11 METAL CHIP 0 5% 1/10W
FB899 1-216-864-11 METAL CHIP 0 5% 1/10W
< IC >
IC101 8-759-710-97 IC NJM4565M-D
IC102 6-703-650-11 IC M61529FP-D60G
IC301 6-703-651-11 IC M61530FP-D60G
IC302 8-749-019-25 IC TOTX141 (DVD DIGITAL OUT (OPTICAL))
IC303 8-759-710-97 IC NJM4565M-D
IC601 6-702-130-01 IC HA12237F
IC703 8-759-532-64 IC M62703SL-TP
IC1104 6-802-957-01 IC M30620MCN-A28FP
< JACK >
J102 1-774-785-11 JACK, PIN 1P (SUB WOOFER OUT)
J104 1-816-918-11 JACK, PIN 4P (MD(VIDEO) IN/OUT)
< JUMPER RESISTOR >
JR1 1-216-864-11 METAL CHIP 0 5% 1/10W
JR2 1-216-864-11 METAL CHIP 0 5% 1/10W
JR3 1-216-864-11 METAL CHIP 0 5% 1/10W
JR4 1-216-864-11 METAL CHIP 0 5% 1/10W
(RV990D)
JR5 1-216-864-11 METAL CHIP 0 5% 1/10W
(RV990D)
JR6 1-216-864-11 METAL CHIP 0 5% 1/10W
JR8 1-216-864-11 METAL CHIP 0 5% 1/10W
JR9 1-216-864-11 METAL CHIP 0 5% 1/10W
JR15 1-216-864-11 METAL CHIP 0 5% 1/10W
JR16 1-216-864-11 METAL CHIP 0 5% 1/10W
JR17 1-216-864-11 METAL CHIP 0 5% 1/10W
JR104 1-216-837-11 METAL CHIP 22K 5% 1/10W
JR105 1-216-837-11 METAL CHIP 22K 5% 1/10W
JR133 1-216-864-11 METAL CHIP 0 5% 1/10W
(RV660D)
JR159 1-216-864-11 METAL CHIP 0 5% 1/10W
JR300 1-216-864-11 METAL CHIP 0 5% 1/10W
(RV660D)
JR456 1-216-864-11 METAL CHIP 0 5% 1/10W
(RV660D)
< COIL >
L341 1-412-064-11 INDUCTOR 100uH
L561 1-408-619-31 INDUCTOR 220uH
< TRANSISTOR >
Q102 8-729-021-15 TRANSISTOR 2SD2351T106W
Q104 8-729-905-35 TRANSISTOR 2SC4081-R
Q106 8-729-021-15 TRANSISTOR 2SD2351T106W
Q114 8-729-021-15 TRANSISTOR 2SD2351T106W
Q115 8-729-021-15 TRANSISTOR 2SD2351T106W
Q151 8-729-905-35 TRANSISTOR 2SC4081-R
Q152 8-729-021-15 TRANSISTOR 2SD2351T106W
Q153 8-729-021-15 TRANSISTOR 2SD2351T106W
Q373 8-729-021-15 TRANSISTOR 2SD2351T106W (RV990D)
Q374 8-729-021-15 TRANSISTOR 2SD2351T106W (RV990D)
Q375 8-729-021-15 TRANSISTOR 2SD2351T106W (RV990D)
Q376 8-729-021-15 TRANSISTOR 2SD2351T106W
Q377 8-729-021-15 TRANSISTOR 2SD2351T106W
Q601 8-729-142-46 TRANSISTOR 2SC2001-LK
Q602 8-729-907-00 TRANSISTOR DTC114EU
Q603 8-729-905-35 TRANSISTOR 2SC4081-R
Q604 8-729-905-35 TRANSISTOR 2SC4081-R
Q605 8-729-905-35 TRANSISTOR 2SC4081-R
Q606 8-729-905-35 TRANSISTOR 2SC4081-R
Q607 8-729-905-35 TRANSISTOR 2SC4081-R
Q608 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q609 8-729-905-35 TRANSISTOR 2SC4081-R
Q610 8-729-905-35 TRANSISTOR 2SC4081-R
Q611 8-729-029-10 TRANSISTOR DTC143TUA-T106
Q612 6-550-044-01 TRANSISTOR 2SB1689-T106
Q613 6-550-044-01 TRANSISTOR 2SB1689-T106
Q614 8-729-907-00 TRANSISTOR DTC114EU
Q615 8-729-907-00 TRANSISTOR DTC114EU
Q616 6-550-044-01 TRANSISTOR 2SB1689-T106
Q617 6-550-044-01 TRANSISTOR 2SB1689-T106
Q618 8-729-907-00 TRANSISTOR DTC114EU
Q701 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q702 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q703 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q704 8-729-907-00 TRANSISTOR DTC114EU
Q705 8-729-905-35 TRANSISTOR 2SC4081-R
Q706 8-729-905-35 TRANSISTOR 2SC4081-R
Q707 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q708 8-729-907-00 TRANSISTOR DTC114EU
Q709 8-729-905-35 TRANSISTOR 2SC4081-R
Q710 8-729-905-35 TRANSISTOR 2SC4081-R
Q713 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q714 8-729-907-00 TRANSISTOR DTC114EU
Q719 8-729-028-73 TRANSISTOR DTA114EUA-T106 (RV990D)
Q721 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q723 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q724 8-729-028-73 TRANSISTOR DTA114EUA-T106 (RV990D)
< RESISTOR >
R102 1-216-864-11 METAL CHIP 0 5% 1/10W
R104 1-216-821-11 METAL CHIP 1K 5% 1/10W
R105 1-216-845-11 METAL CHIP 100K 5% 1/10W
R109 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R111 1-216-833-11 METAL CHIP 10K 5% 1/10W
R116 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-841-11 METAL CHIP 47K 5% 1/10W
R119 1-216-818-11 METAL CHIP 560 5% 1/10W
0 R120 1-215-890-11 METAL OXIDE 470 5% 2W F
R121 1-216-821-11 METAL CHIP 1K 5% 1/10W
R122 1-216-821-11 METAL CHIP 1K 5% 1/10W
R123 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R124 1-216-821-11 METAL CHIP 1K 5% 1/10W
R125 1-216-845-11 METAL CHIP 100K 5% 1/10W
Ref. No. Part No. Description Remark
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
