Sony HCD-RX55 - MAIN SECTION ELECTRICAL PARTS LIST; Motor (6 P)(S) and Panel Parts List

Ref. No. Part No. Description Remarks
— 78 —
Ref. No. Part No. Description Remarks
* 1-670-445-11 FUSE BOARD
***********
1-533-293-11 FUSE HOLDER
< TERMINAL >
AC1 1-535-416-00 TERMINAL
AC2 1-535-416-00 TERMINAL
P6 1-535-416-00 TERMINAL
P7 1-535-416-00 TERMINAL
< FUSE >
! F702 1-576-108-11 FUSE 4A/125V
< RESISTOR >
! R001 1-202-727-00 CARBON 4.7M 5% 1/3W (US,CND)
************************************************************
* A-4405-480-A MAIN BOARD, COMPLETE (US,CND)
*********************
* A-4405-482-A MAIN BOARD, COMPLETE (E,AUS,SP,MY,TW)
*********************
* A-4405-483-A MAIN BOARD, COMPLETE (MX)
*********************
< CAPACITOR >
C101 1-161-379-00 CERAMIC 0.01uF 20% 25V
C102 1-161-379-00 CERAMIC 0.01uF 20% 25V
C103 1-162-195-31 CERAMIC 4.7PF 10% 50V
C104 1-161-494-00 CERAMIC 0.022uF 25V
C105 1-162-206-31 CERAMIC 20PF 5% 50V
C106 1-161-494-00 CERAMIC 0.022uF 25V
C108 1-126-933-11 ELECT 100uF 20% 16V
C109 1-162-191-31 CERAMIC 2.2PF 10% 50V
C110 1-162-191-31 CERAMIC 2.2PF 10% 50V
C111 1-162-217-31 CERAMIC 56PF 5% 50V
C112 1-162-294-31 CERAMIC 0.001uF 10% 50V
C115 1-161-379-00 CERAMIC 0.01uF 20% 25V
C116 1-130-014-00 FILM 470PF 5% 50V
C117 1-162-205-31 CERAMIC 18PF 5% 50V
C118 1-126-933-11 ELECT 100uF 20% 16V
C120 1-161-494-00 CERAMIC 0.022uF 25V
C121 1-162-203-31 CERAMIC 15PF 5% 50V
C122 1-126-961-11 ELECT 2.2uF 20% 50V
C123 1-126-960-11 ELECT 1uF 20% 50V
C124 1-162-206-31 CERAMIC 20PF 5% 50V
C125 1-126-960-11 ELECT 1uF 20% 50V
C126 1-110-671-31 CERAMIC 47000PF 50V
C127 1-126-964-11 ELECT 10uF 20% 50V
C128 1-161-494-00 CERAMIC 0.022uF 25V
C129 1-109-889-11 ELECT 1uF 20% 50V
C130 1-161-054-00 CERAMIC 0.018uF 10% 25V
C131 1-161-054-00 CERAMIC 0.018uF 10% 25V
C132 1-161-051-00 CERAMIC 0.01uF 10% 50V
C133 1-161-051-00 CERAMIC 0.01uF 10% 50V
C137 1-126-959-11 ELECT 0.47uF 20% 50V
C140 1-126-933-11 ELECT 100uF 20% 16V
C141 1-161-494-00 CERAMIC 0.022uF 25V
C142 1-126-933-11 ELECT 100uF 20% 16V
C143 1-126-959-11 ELECT 0.47uF 20% 50V
C144 1-161-494-00 CERAMIC 0.022uF 25V
C145 1-162-217-31 CERAMIC 56PF 5% 50V
C146 1-161-744-00 CERAMIC 0.01uF 250V
C148 1-161-494-00 CERAMIC 0.022uF 25V
C149 1-161-744-00 CERAMIC 0.01uF 250V
C151 1-128-551-11 ELECT 22uF 20% 25V
C152 1-162-294-31 CERAMIC 0.001uF 10% 50V
C154 1-162-294-31 CERAMIC 0.001uF 10% 50V
C155 1-162-294-31 CERAMIC 0.001uF 10% 50V
C156 1-102-516-11 CERAMIC 27PF 5% 50V
C157 1-102-516-11 CERAMIC 27PF 5% 50V
C158 1-126-967-11 ELECT 47uF 20% 16V
C159 1-164-159-11 CERAMIC 0.1uF 50V
C160 1-126-963-11 ELECT 4.7uF 20% 50V
C161 1-126-963-11 ELECT 4.7uF 20% 50V
C162 1-161-494-00 CERAMIC 0.022uF 25V
C163 1-161-494-00 CERAMIC 0.022uF 25V
C164 1-126-962-11 ELECT 3.3uF 20% 50V
C166 1-161-494-00 CERAMIC 0.022uF 25V
C167 1-162-282-31 CERAMIC 100PF 10% 50V
C175 1-130-485-00 MYLAR 0.015uF 5% 50V
C176 1-130-485-00 MYLAR 0.015uF 5% 50V
C177 1-161-494-00 CERAMIC 0.022uF 25V
C181 1-164-159-11 CERAMIC 0.1uF 50V
C301 1-164-159-11 CERAMIC 0.1uF 50V
C302 1-162-306-11 CERAMIC 0.01uF 20% 16V
C303 1-162-306-11 CERAMIC 0.01uF 20% 16V
C305 1-126-959-11 ELECT 0.47uF 20% 50V
C306 1-126-959-11 ELECT 0.47uF 20% 50V
C307 1-126-959-11 ELECT 0.47uF 20% 50V
C308 1-126-959-11 ELECT 0.47uF 20% 50V
C309 1-162-282-31 CERAMIC 100PF 10% 50V
C310 1-162-282-31 CERAMIC 100PF 10% 50V
C311 1-126-959-11 ELECT 0.47uF 20% 50V
C312 1-126-959-11 ELECT 0.47uF 20% 50V
C313 1-137-150-11 FILM 0.01uF 5% 100V
C314 1-137-150-11 FILM 0.01uF 5% 100V
C317 1-136-479-11 FILM 0.001uF 5% 100V
C318 1-136-479-11 FILM 0.001uF 5% 100V
C319 1-136-480-11 FILM 0.0015uF 5% 100V
C320 1-136-480-11 FILM 0.0015uF 5% 100V
C321 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C322 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C325 1-137-350-11 FILM 0.015uF 5% 100V
C326 1-137-350-11 FILM 0.015uF 5% 100V
C327 1-126-934-11 ELECT 220uF 20% 16V
C328 1-126-934-11 ELECT 220uF 20% 16V
C329 1-162-282-31 CERAMIC 100PF 10% 50V
C330 1-162-282-31 CERAMIC 100PF 10% 50V
C331 1-126-960-11 ELECT 1uF 20% 50V
C332 1-126-960-11 ELECT 1uF 20% 50V
C333 1-126-933-11 ELECT 100uF 20% 16V
C334 1-126-960-11 ELECT 1uF 20% 50V
C335 1-126-960-11 ELECT 1uF 20% 50V
C336 1-126-962-11 ELECT 3.3uF 20% 50V
C337 1-126-962-11 ELECT 3.3uF 20% 50V
C339 1-126-959-11 ELECT 0.47uF 20% 50V
C340 1-126-959-11 ELECT 0.47uF 20% 50V
FUSE
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MAIN
