Sony HCD-RX55 - PARTS LIST CORRECTIONS; Capacitor, Diode, IC, and Connector Corrections

––––––––––– ––––––––––––––––––––––
1-126-925-11 ELECT 470uF 20% 10V
1-162-201-31 CERAMIC 12PF 5% 50V
––––––––––– ––––––––––––––––––––––
1-162-294-31 CERAMIC 0.001uF 10% 50V
––––––––––– ––––––––––––––––––––––
1-136-154-00 FILM 0.012uF 5% 50V
1-162-306-11 CERAMIC 0.01uF 20% 16V
1-126-927-11 ELECT 2200uF 20% 10V
1-162-294-31 CERAMIC 0.001uF 10% 50V
1-102-942-00 CERAMIC 5PF 0.5PF 50V
1-102-942-00 CERAMIC 5PF 0.5PF 50V
1-126-934-11 ELECT 220uF 20% 10V
1-162-289-31 CERAMIC 390PF 10% 50V
1-162-289-31 CERAMIC 390PF 10% 50V
1-162-288-31 CERAMIC 330PF 10% 50V
1-162-288-31 CERAMIC 330PF 10% 50V
1-162-288-31 CERAMIC 330PF 10% 50V
1-162-288-31 CERAMIC 330PF 10% 50V
––––––––––– ––––––––––––––––––––––
1-162-294-31 CERAMIC 0.001uF 10% 50V
1-162-294-31 CERAMIC 0.001uF 10% 50V
1-162-294-31 CERAMIC 0.001uF 10% 50V
1-162-294-31 CERAMIC 0.001uF 10% 50V
1-164-159-11 CERAMIC 0.1uF 50V
8-719-991-33 DIODE ISS133T
8-719-921-41 DIODE MTZJ-5.1
8-719-991-33 DIODE ISS133T
8-759-234-75 IC TC74HC4094AP
8-759-579-80 IC BA5936S
1-249-393-11 CARBON 10 5% 1/4W
1-249-438-11 CARBON 56K 5% 1/4W
1-249-440-11 CARBON 82K 5% 1/4W
1-249-431-11 CARBON 15K 5% 1/4W
1-249-385-11 CARBON 2.2 5% 1/4W
1-274-871-11 CARBON 47K 5% 1/4W
1-249-411-11 CARBON 330 5% 1/4W
1-247-867-11 CARBON 33K 5% 1/4W
1-249-432-11 CARBON 18K 5% 1/4W
1-249-417-11 CARBON 1K 5% 1/4W
1-247-867-11 CARBON 33K 5% 1/4W
1-247-867-11 CARBON 33K 5% 1/4W
1-247-867-11 CARBON 33K 5% 1/4W
1-247-867-11 CARBON 33K 5% 1/4W
1-249-409-11 CARBON 220 5% 1/4W
1-249-432-11 CARBON 18K 5% 1/4W
1-247-855-11 CARBON 10K 5% 1/4W
1-249-432-11 CARBON 18K 5% 1/4W
1-247-855-11 CARBON 10K 5% 1/4W
1-247-867-11 CARBON 33K 5% 1/4W
1-247-863-11 CARBON 22K 5% 1/4W
1-670-801-11 MOTOR BOARD
************
<CAPACITOR>
1-126-963-11 ELECT 4.7uF 20% 50V
1-164-159-11 CERAMIC 0.1uF 50V
<CONNECTOR>
1-568-824-11 SOCKET, CONNECTOR 5P
• PARTS LIST
Page CORRECT
Ref. No. Part No. Description Remarks Part No. Description Remarks
C02 1-126-963-11 ELECT 4.7uF 20% 50V
C04B ––––––––––– ––––––––––––––––––––––
C07A 1-162-199-31 CERAMIC 10PF 5% 50V
C08 1-161-494-00 CERAMIC 0.022uF 25V
C23A ––––––––––– ––––––––––––––––––––––
C26 1-161-494-00 CERAMIC 0.022uF 25V
C27 1-162-306-11 CERAMIC 0.01uF 20% 16V
C28 1-164-159-11 CERAMIC 0.1uF 50V
C29A ––––––––––– ––––––––––––––––––––––
C30B ––––––––––– ––––––––––––––––––––––
C38 1-102-958-00 CERAMIC 20PF 5% 50V
C39 1-102-958-00 CERAMIC 20PF 5% 50V
C46 1-126-933-11 ELECT 100uF 20% 10V
C51 1-162-288-31 CERAMIC 330PF 10% 50V
C52 1-162-288-31 CERAMIC 330PF 10% 50V
C53 1-162-284-31 CERAMIC 150PF 10% 50V
C54 1-162-284-31 CERAMIC 150PF 10% 50V
C55 1-162-284-31 CERAMIC 150PF 10% 50V
C56 1-162-284-31 CERAMIC 150PF 10% 50V
C84 1-162-282-31 CERAMIC 100PF 10% 50V
C85 1-162-292-31 CERAMIC 680PF 10% 50V
C86 1-162-282-31 CERAMIC 100PF 10% 50V
C87 1-162-282-31 CERAMIC 100PF 10% 50V
C88 1-162-282-31 CERAMIC 100PF 10% 50V
C90 1-161-494-00 CERAMIC 0.022uF 25V
D01 8-719-911-19 DIODE ISS119-25
D04 8-719-921-41 DIODE ISS113T
D04A 8-719-991-33 DIODE ISS176
IC02 8-759-388-27 IC TC9173P
IC03 8-759-429-31 IC BA5941FP
R03 1-249-397-11 CARBON 22 5% 1/4W
R14 1-247-879-11 CARBON 100K 5% 1/4W
R15 1-247-881-00 CARBON 120K 5% 1/4W
R26 1-247-855-11 CARBON 10K 5% 1/4W
R27 1-249-430-11 CARBON 12K 5% 1/4W
R28 1-247-855-11 CARBON 10K 5% 1/4W
R36 1-247-847-11 CARBON 4.7K 5% 1/4W
R50 1-247-847-11 CARBON 4.7K 5% 1/4W
R53 1-249-411-11 CARBON 330 5% 1/4W
R58 1-249-442-11 CARBON 510 5% 1/4W
R65 1-247-864-11 CARBON 24K 5% 1/4W
R66 1-247-864-11 CARBON 24K 5% 1/4W
R67 1-247-864-11 CARBON 24K 5% 1/4W
R68 1-247-864-11 CARBON 24K 5% 1/4W
R79 1-249-405-11 CARBON 100 5% 1/4W
R89 1-247-839-11 CARBON 2.2K 5% 1/4W
R90 1-247-839-11 CARBON 2.2K 5% 1/4W
R91 1-247-839-11 CARBON 2.2K 5% 1/4W
R92 1-247-839-11 CARBON 2.2K 5% 1/4W
R93 1-249-420-11 CARBON 1.8K 5% 1/4W
R94 1-249-420-11 CARBON 1.8K 5% 1/4W
* ––––––––––– ––––––––––––––––––––––
C01 ––––––––––– ––––––––––––––––––––––
C82 ––––––––––– ––––––––––––––––––––––
* CN06 ––––––––––– ––––––––––––––––––––––
INCORRECT
74
75
76
81
— 2 —
