SERVICE MANUAL
Subject: ADDITION OF AR MODEL AND
CORRECTION OF HCD-R300 (BLACK MODEL)
HCD-GRX3/RX55/R300
US Model
Canadian Model
HCD-RX55
E Model
HCD-GRX3/R300
Australian Model
HCD-GRX3
PAGE
Former
New
67
Ref. No. Part No. Description Remark
MECHANICAL PARTS LIST
* 2 4-210-616-01 COVER (-GRX), TOP
* 4 A-4405-480-A MAIN BOARD, COMPLETE (US,CND)
* 4 A-4405-482-A MAIN BOARD, COMPLETE
(E,AUS,SP,MY,TW)
10 3-703-571-11 BUSHING (S) (4516), CORD
(US,CND,E,MX)
! PT302 1-431-952-11 TRANSFORMER, POWER
(E,AUS,SP,MY,TW)
Ref. No. Part No. Description Remark
MECHANICAL PARTS LIST
* 2 4-210-616-01 COVER (-GRX), TOP (GRX3)
* 2 4-210-589-01 COVER, TOP (RX55)
* 2 4-211-426-01 COVER, TOP (R300)
* 4 A-4405-480-A MAIN BOARD, COMPLETE (US,CND,MX)
* 4 A-4405-482-A MAIN BOARD, COMPLETE
(E,AUS,SP,MY,TW,AR)
! 9 1-783-941-11 CORD, POWER (AR)
10 3-703-571-11 BUSHING (S) (4516), CORD
(US,CND,E,MX,AR)
! PT302 1-431-952-11 TRANSFORMER, POWER
(E,AUS,SP,MY,TW,AR)
(SPM-00011)
SUPPLEMENT-1
File this suppulement with the service manual.
The others are common parts so that please refer to the previous issued service manual.
• Items marked “*” are not stocked since they are seldom required for routine service.
Some delay should be anticipated when ordering these items.
ADDITION OF AR MODEL AND CORRECTION OF HCD-R300 (BLACK MODEL)
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
• Abbreviation
CND : Canadian model
SP : Singapore model
MY : Malaysia model
TW : Taiwan model
MX : Mexican model
AUS : Australian model
AR : Argentine model
To Next Page
