HCD-SPZ90DAB
Pin No.
Pin Name I/O Description
90
TC HALF/REC SW
I
Cassette detection signal and recording-proof detection signal input from the tape mechanism deck
block "L": cassette in or recording possible
91 to 93
KEY3 to KEY1 I Front panel key input terminal (A/D input)
94
VOLUME
I
Jog dial pulse input from the rotary encoder (VOLUME) (A/D input)
95
JOG
I
Jog dial pulse input from the rotary encoder (jog) (A/D input)
96
AVSS - Ground terminal
97
SPEC IN I Setting terminal for the model and destination
98
VREF I Reference voltage (+3.3V) input terminal
99
AVCC - Power supply terminal (+3.3V)
100
AUDIO IN
DETECT
I Audio in plug insert detection signal input terminal "H": audio in plug insert
