Sony HCD-SPZ90DAB - AMP;SP;POWER BOARDS; DAB MODULE ASSY

HCD-SPZ90DAB
9
6 connector
(CNP891)
8 connector
(CN500)
7
1
three screw
s
(B3 )
5 three screws
(B3
)
2 screw
(B3
)
3 screw
(B3
)
4 chassis
9 DAB module assy
DAB board
3 AMP board
0 POWER board
2 four screws
(B3)
6 connector
(CN1)
7 connector
(CN31)
8 two screws
(B3)
5 SP board
4 two screws
(BVTP
3 × 8
)
9 screws
(B
3)
1 two connectors
(CN850, CN870)
3-7. AMP/SP/POWER BOARDS
3-8. DAB MODULE ASSY
