HCD-VM330AV
Pin No. Pin Name I/O Description
121 HSEL I
Command selection signal input from the video CD controller (IC502)
122 CDG-SDATA I
Not used (fixed at “L”)
123 CDG-VFSY I
Not used (fixed at “L”)
124 CDG-S0S1 I
Not used (fixed at “L”)
125 to 128 NC O
Not used (open)
