HCD-VM330AV
8
3-3. FRONT BLOCK ASSY
Note: Follow the disassembly procedure in the numerical order given.
3-2. UPPER COVER
1
three screws
(BVTP3
×
8)
2
five screws
(BVTP3
×
8)
2
two screws
(BVTP3
×
8)
3
upper cover
1
three screws
(BVTP3
×
8)
7
two bosses
6
screw (KTP3
×
8)
3
screw (BVTP3
×
8)
4
two herness
5
three screws
(BVTP3
×
8)
6
screw (KTP3
×
8)
8
front block assy
7
two bosses
2
three connectors
(CN310, 503, 803)
2
connector (CN315)
1
wire (flat type) (10 core)
(CN311)
1
wire (flat type) (11 core)
(CN312)
1
wire (flat type) (17 core)
(CN301)
