64
HCD-VM330AV
Pin No. Pin Name I/O Description
84 C-SENS I
Internal status monitor input terminal Not used (open)
85 C-DATA O
Command serial data output terminal Not used (open)
86 C-LATCH O
Command latch pulse output terminal Not used (open)
87 C-CLK O
Command serial data transfer clock signal output terminal Not used (open)
88 LD ON I
Laser diode on/off control signal output terminal Not used (open)
89 B-SHUT I
Shut off detection signal input from the deck-B side reel pulse detector in the tape mechanism
deck section
90 B-HALF I
Detection input from the deck-B cassette detect switch in the tape mechanism deck section
“L”: cassette in
91 T-SENS3 I
Table position sensor (IC12) input terminal
92 D-SENS I
Disc detect sensor (Q841) input terminal “H”: disc in
93 T-SENS1 I
Table position sensor (IC11) input terminal
94
SPEC I Model specification setting terminal
95 MODEL
I Model destination setting terminal
96
AVSS — Ground terminal (analog system)
97 A-SHUT I
Shut off detection signal input from the deck-A side reel pulse detector in the tape mechanism
deck section
98
VREF
I
Reference voltage (+5V) input terminal (for A/D converter)
99 AVCC —
Power supply terminal (+5V) (for A/D conversion)
100 TABLE NEG O
Table motor drive signal (clockwise) output to the motor driver (IC881)
