Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
78
HCD-VM330AV
< GROUND TERMINAL >
GP301 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC301 8-759-571-51 IC M62464FP
IC302 6-700-261-01 IC BD3861FS
IC303 8-759-909-71 IC BA4558F-E2
IC304 8-759-909-71 IC BA4558F-E2
IC306 8-759-932-33 IC BU4066BC
IC307 8-759-932-33 IC BU4066BC
IC309 8-759-295-90 IC NJM2244M-TE2
IC361 8-749-923-04 IC TOTX178A
IC801 6-800-253-01 IC M30622MGA-A57FP
IC802 8-759-637-58 IC PST592C-T
IC881 8-759-356-03 IC BA6780
IC901 8-759-347-18 IC KIA7809PI
IC903 8-759-646-54 IC KIA7808API
IC904 8-759-646-52 IC KIA7805API
IC905 8-759-646-52 IC KIA7805API
IC906 8-759-646-52 IC KIA7805API
< JACK >
J301 1-815-578-11 PIN JACK (PHONO) 6P (5.1CH INPUT FRONT,
REAR, CENTER, SUB WOOFER)
J302 1-815-577-11 PIN JACK (PHONO) 2P (VIDEO (MD) IN)
J303 1-815-576-11 PIN JACK (PHONO) 1P (SUB WOOFER OUT)
J304 1-815-574-11 PIN JACK (PHONO) 1P (VIDEO OUT)
< COIL >
L301 1-410-517-11 INDUCTOR 47uH
L302 1-410-521-11 INDUCTOR 100uH
L303 1-410-517-11 INDUCTOR 47uH
L304 1-410-517-11 INDUCTOR 47uH
< TRANSISTOR >
Q101 8-729-036-89 TRANSISTOR KTC3198GR-A
Q102 8-729-036-89 TRANSISTOR KTC3198GR-A
Q112 8-729-036-89 TRANSISTOR KTC3198GR-A
Q141 8-729-036-89 TRANSISTOR KTC3198GR-A
Q142 8-729-036-89 TRANSISTOR KTC3198GR-A
Q201 8-729-036-89 TRANSISTOR KTC3198GR-A
Q202 8-729-036-89 TRANSISTOR KTC3198GR-A
Q212 8-729-036-89 TRANSISTOR KTC3198GR-A
Q232 8-729-905-50 TRANSISTOR DTC343TS
Q241 8-729-036-89 TRANSISTOR KTC3198GR-A
Q242 8-729-036-89 TRANSISTOR KTC3198GR-A
Q333 8-759-068-54 TRANSISTOR KRA102S
Q334 8-729-038-67 TRANSISTOR KRC102S
Q341 8-759-068-54 TRANSISTOR KRA102S
Q342 8-729-038-67 TRANSISTOR KRC102S
Q343 8-759-068-54 TRANSISTOR KRA102S
Q344 8-729-038-67 TRANSISTOR KRC102S
Q350 8-729-038-67 TRANSISTOR KRC102S
Q351 8-759-068-54 TRANSISTOR KRA102S
Q352 8-729-212-02 TRANSISTOR KTC3203Y-AT
Q361 8-729-038-67 TRANSISTOR KRC102S
Q362 8-729-821-08 TRANSISTOR 2SB1013-TP-34
Q381 8-729-202-56 TRANSISTOR 2SA950-Y-TPE2
Q382 8-729-038-67 TRANSISTOR KRC102S
Q383 8-729-202-56 TRANSISTOR 2SA950-Y-TPE2
Q384 8-729-038-67 TRANSISTOR KRC102S
Q385 8-729-202-56 TRANSISTOR 2SA950-Y-TPE2
Q386 8-729-038-67 TRANSISTOR KRC102S
Q391 8-729-202-56 TRANSISTOR 2SA950-Y-TPE2
Q392 8-729-038-67 TRANSISTOR KRC102S
Q397 8-729-037-13 TRANSISTOR KTA1271Y-AT
Q801 8-729-036-89 TRANSISTOR KTC3198GR-A
Q802 8-729-212-02 TRANSISTOR KTC3203Y-AT
Q803 8-729-212-02 TRANSISTOR KTC3203Y-AT
Q881 8-759-068-54 TRANSISTOR KRA102S
Q882 8-729-038-67 TRANSISTOR KRC102S
Q883 8-759-068-54 TRANSISTOR KRA102S
Q884 8-729-038-67 TRANSISTOR KRC102S
Q885 8-759-068-54 TRANSISTOR KRA102S
Q886 8-729-038-67 TRANSISTOR KRC102S
Q887 8-759-068-54 TRANSISTOR KRA102S
Q888 8-729-038-67 TRANSISTOR KRC102S
Q902 8-729-019-00 TRANSISTOR KTC2026
< RESISTOR >
R101 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R102 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R103 1-216-845-11 METAL CHIP 100K 5% 1/16W
R104 1-216-845-11 METAL CHIP 100K 5% 1/16W
R105 1-216-841-11 METAL CHIP 47K 5% 1/16W
R106 1-216-835-11 METAL CHIP 15K 5% 1/16W
R107 1-216-833-11 METAL CHIP 10K 5% 1/16W
R108 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R109 1-216-845-11 METAL CHIP 100K 5% 1/16W
R110 1-216-835-11 METAL CHIP 15K 5% 1/16W
R111 1-216-835-11 METAL CHIP 15K 5% 1/16W
R112 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R113 1-216-845-11 METAL CHIP 100K 5% 1/16W
R114 1-216-833-11 METAL CHIP 10K 5% 1/16W
R115 1-216-845-11 METAL CHIP 100K 5% 1/16W
R116 1-216-845-11 METAL CHIP 100K 5% 1/16W
R117 1-216-837-11 METAL CHIP 22K 5% 1/16W
R119 1-216-821-11 METAL CHIP 1K 5% 1/16W
R120 1-216-835-11 METAL CHIP 15K 5% 1/16W
R121 1-216-835-11 METAL CHIP 15K 5% 1/16W
R122 1-216-845-11 METAL CHIP 100K 5% 1/16W
R123 1-216-833-11 METAL CHIP 10K 5% 1/16W
R124 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R126 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R130 1-216-835-11 METAL CHIP 15K 5% 1/16W
R131 1-216-835-11 METAL CHIP 15K 5% 1/16W
R141 1-216-839-11 METAL CHIP 33K 5% 1/16W
R142 1-216-847-11 METAL CHIP 150K 5% 1/16W
R143 1-216-824-11 RES, CHIP 1.8K 5% 1/16W
R144 1-216-833-11 METAL CHIP 10K 5% 1/16W
R145 1-216-854-11 RES, CHIP 560K 5% 1/16W
R147 1-216-837-11 METAL CHIP 22K 5% 1/16W
R148 1-216-833-11 METAL CHIP 10K 5% 1/16W
R171 1-216-841-11 METAL CHIP 47K 5% 1/16W
R174 1-216-845-11 METAL CHIP 100K 5% 1/16W
