Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
85
HCD-VM330AV
Q502 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q531 8-729-140-75 TRANSISTOR 2SD999-T1-CLCK
< RESISTOR >
R101 1-216-833-11 METAL CHIP 10K 5% 1/16W
R102 1-218-851-11 METAL CHIP 1.5K 0.5% 1/16W
R103 1-218-851-11 METAL CHIP 1.5K 0.5% 1/16W
R201 1-216-833-11 METAL CHIP 10K 5% 1/16W
R202 1-218-851-11 METAL CHIP 1.5K 0.5% 1/16W
R203 1-218-851-11 METAL CHIP 1.5K 0.5% 1/16W
R301 1-216-833-11 METAL CHIP 10K 5% 1/16W
R302 1-211-990-11 METAL CHIP 75 0.5% 1/16W
R303 1-211-990-11 METAL CHIP 75 0.5% 1/16W
R304 1-216-809-11 METAL CHIP 100 5% 1/16W
R305 1-216-809-11 METAL CHIP 100 5% 1/16W
R306 1-211-990-11 METAL CHIP 75 0.5% 1/16W
R308 1-216-833-11 METAL CHIP 10K 5% 1/16W
R309 1-216-833-11 METAL CHIP 10K 5% 1/16W
R310 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R311 1-216-811-11 METAL CHIP 150 5% 1/16W
R312 1-216-833-11 METAL CHIP 10K 5% 1/16W
R313 1-216-833-11 METAL CHIP 10K 5% 1/16W
R314 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R315 1-218-285-11 RES-CHIP 75 5% 1/16W
R316 1-218-285-11 RES-CHIP 75 5% 1/16W
R317 1-218-285-11 RES-CHIP 75 5% 1/16W
R319 1-211-990-11 METAL CHIP 75 0.5% 1/16W
R403 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R404 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R501 1-216-809-11 METAL CHIP 100 5% 1/16W
R502 1-216-809-11 METAL CHIP 100 5% 1/16W
R503 1-216-809-11 METAL CHIP 100 5% 1/16W
R504 1-216-809-11 METAL CHIP 100 5% 1/16W
R505 1-216-809-11 METAL CHIP 100 5% 1/16W
R506 1-216-809-11 METAL CHIP 100 5% 1/16W
R507 1-216-833-11 METAL CHIP 10K 5% 1/16W
R508 1-216-833-11 METAL CHIP 10K 5% 1/16W
R511 1-216-833-11 METAL CHIP 10K 5% 1/16W
R512 1-216-833-11 METAL CHIP 10K 5% 1/16W
R513 1-216-833-11 METAL CHIP 10K 5% 1/16W
R516 1-216-833-11 METAL CHIP 10K 5% 1/16W
R517 1-216-833-11 METAL CHIP 10K 5% 1/16W
R518 1-216-833-11 METAL CHIP 10K 5% 1/16W
R519 1-216-809-11 METAL CHIP 100 5% 1/16W
R520 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R521 1-216-833-11 METAL CHIP 10K 5% 1/16W
R523 1-216-803-11 METAL CHIP 33 5% 1/16W
R524 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R526 1-216-849-11 METAL CHIP 220K 5% 1/16W
R528 1-216-845-11 METAL CHIP 100K 5% 1/16W
R530 1-216-809-11 METAL CHIP 100 5% 1/16W
R531 1-216-809-11 METAL CHIP 100 5% 1/16W
R532 1-216-864-11 METAL CHIP 0 5% 1/16W
R533 1-216-864-11 METAL CHIP 0 5% 1/16W
R534 1-216-833-11 METAL CHIP 10K 5% 1/16W
R535 1-216-833-11 METAL CHIP 10K 5% 1/16W
R536 1-216-813-11 METAL CHIP 220 5% 1/16W
R537 1-216-809-11 METAL CHIP 100 5% 1/16W
R538 1-216-833-11 METAL CHIP 10K 5% 1/16W
R539 1-216-864-11 METAL CHIP 0 5% 1/16W
R540 1-216-864-11 METAL CHIP 0 5% 1/16W
R542 1-218-847-11 METAL CHIP 1K 0.5% 1/16W
R543 1-218-881-11 METAL CHIP 27K 0.5% 1/16W
R544 1-218-855-11 METAL CHIP 2.2K 0.5% 1/16W
R545 1-216-809-11 METAL CHIP 100 5% 1/16W
R546 1-216-821-11 METAL CHIP 1K 5% 1/16W
R548 1-216-821-11 METAL CHIP 1K 5% 1/16W
R549 1-216-809-11 METAL CHIP 100 5% 1/16W
R550 1-216-809-11 METAL CHIP 100 5% 1/16W
R551 1-216-809-11 METAL CHIP 100 5% 1/16W
R552 1-216-809-11 METAL CHIP 100 5% 1/16W
R555 1-216-857-11 METAL CHIP 1M 5% 1/16W
R556 1-216-809-11 METAL CHIP 100 5% 1/16W
R557 1-216-809-11 METAL CHIP 100 5% 1/16W
R560 1-218-849-11 METAL CHIP 1.2K 0.5% 1/16W
R561 1-218-847-11 METAL CHIP 1K 0.5% 1/16W
R562 1-216-833-11 METAL CHIP 10K 5% 1/16W
R564 1-216-837-11 METAL CHIP 22K 5% 1/16W
R577 1-216-837-11 METAL CHIP 22K 5% 1/16W
R578 1-216-837-11 METAL CHIP 22K 5% 1/16W
R579 1-216-833-11 METAL CHIP 10K 5% 1/16W
R580 1-216-833-11 METAL CHIP 10K 5% 1/16W
< VIBRATOR >
X501 1-781-155-21 VIBRATOR, CERAMIC (10MHz)
X503 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
**************************************************************
1-680-804-31 VOL SEL BOARD
*************
< SWITCH >
0 S901 1-786-152-11 SWITCH, SLIDE (VOLTAGE SELECTOR)
**************************************************************
MISCELLANEOUS
**************
4 1-757-998-11 WIRE (FLAT TYPE) (13CORE)
5 1-823-000-11 WIRE (FLAT TYPE) (18CORE)
6 1-757-997-11 WIRE (FLAT TYPE) (10CORE)
7 1-823-001-11 WIRE (FLAT TYPE) (11CORE)
8 1-823-004-11 WIRE (FLAT TYPE) (17CORE)
13 1-823-257-11 WIRE (FLAT TYPE) (25CORE)
77 1-796-078-11 DECK, MECH
89 1-757-999-11 WIRE (FLAT TYPE) (12CORE)
0 105 1-823-002-11 CORD, POWER
602 1-782-817-11 WIRE (FLAT TYPE) (16CORE)
0 603 A-4735-189-A BU-30 (61) ASSY
M51 A-4735-051-A MOTOR (60) ASSY (LOADING)
M52 A-4735-051-A MOTOR (60) ASSY (TABLE)
M391 1-763-697-11 DC FAN
S791 1-692-960-21 SWITCH, PUSH (1 KEY) (CD LID OPEN)
0 T901 1-437-290-11 TRANSFORMER, POWER
************************************************************
VIDEO VOL SEL
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
