– 126 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
< JACK >
J701 1-766-558-41 JACK, PIN 8P
(VIDEO 1 (AUDIO) IN, PHONO IN, MD OUT)
J702 1-770-336-11 JACK, PIN 2P (VIDEO 1 (VIDEO) IN, VIDEO OUT)
< JUMPER RESISTOR >
JR1 1-216-295-91 SHORT 0
JR2 1-216-296-91 SHORT 0
JR3 1-216-296-91 SHORT 0
JR4 1-216-295-91 SHORT 0
JR5 1-216-295-91 SHORT 0
JR6 1-216-296-91 SHORT 0
JR7 1-216-296-91 SHORT 0
JR8 1-216-296-91 SHORT 0
JR9 1-216-295-91 SHORT 0
JR10 1-216-296-91 SHORT 0
JR11 1-216-296-91 SHORT 0
JR181 1-216-295-91 SHORT 0
JR182 1-216-295-91 SHORT 0
JR192 1-216-295-91 SHORT 0
JR519 1-216-295-91 SHORT 0
JR532 1-216-295-91 SHORT 0
JR533 1-216-295-91 SHORT 0
JR556 1-216-295-91 SHORT 0
JR594 1-216-295-91 SHORT 0
JR703 1-216-295-91 SHORT 0
JR907 1-216-295-91 SHORT 0
JR911 1-216-295-91 SHORT 0
JR921 1-216-296-91 SHORT 0
< COIL >
L781 1-412-032-11 INDUCTOR CHIP 100uH
< TRANSISTOR >
Q111 8-729-620-05 TRANSISTOR 2SC2603-EF
Q112 8-729-620-05 TRANSISTOR 2SC2603-EF
Q113 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q115 8-729-029-86 TRANSISTOR DTC124ESA
Q161 8-729-620-05 TRANSISTOR 2SC2603-EF
Q162 8-729-620-05 TRANSISTOR 2SC2603-EF
Q163 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q165 8-729-029-86 TRANSISTOR DTC124ESA
Q331 8-729-118-00 TRANSISTOR 2SB1116-L
Q332 8-729-029-66 TRANSISTOR DTC114ESA
Q333 8-729-118-00 TRANSISTOR 2SB1116-L
Q334 8-729-029-66 TRANSISTOR DTC114ESA
Q335 8-729-029-66 TRANSISTOR DTC114ESA
Q336 8-729-116-59 TRANSISTOR 2SB1068TP
Q337 8-729-045-21 TRANSISTOR 2SD1513TP-LK
Q338 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q339 8-729-029-66 TRANSISTOR DTC114ESA
Q340 8-729-116-59 TRANSISTOR 2SB1068TP
Q341 8-729-045-21 TRANSISTOR 2SD1513TP-LK
Q342 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q343 8-729-029-66 TRANSISTOR DTC114ESA
Q801 8-729-620-05 TRANSISTOR 2SC2603-EF
Q802 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q803 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q804 8-729-029-40 TRANSISTOR DTA124ESA
Q901 8-729-040-20 TRANSISTOR RT1P137L-TP
Q902 8-729-029-40 TRANSISTOR DTA124ESA
Q903 8-729-040-19 TRANSISTOR RT1N137L-TP
Q904 8-729-029-86 TRANSISTOR DTC124ESA
Q905 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q906 8-729-029-68 TRANSISTOR DTC114TSA
Q911 8-729-040-20 TRANSISTOR RT1P137L-TP
Q912 8-729-029-86 TRANSISTOR DTC124ESA
Q914 8-729-029-86 TRANSISTOR DTC124ESA
Q921 8-729-018-59 TRANSISTOR 2SB1375-LC
Q931 8-729-040-20 TRANSISTOR RT1P137L-TP
Q932 8-729-029-86 TRANSISTOR DTC124ESA
Q961 8-729-620-05 TRANSISTOR 2SC2603-EF
Q962 8-729-118-00 TRANSISTOR 2SB1116-L
< RESISTOR >
R111 1-216-073-00 METAL CHIP 10K 5% 1/10W
R112 1-216-121-91 RES,CHIP 1M 5% 1/10W
R113 1-216-101-00 METAL CHIP 150K 5% 1/10W
(VR70)
R113 1-216-103-00 METAL CHIP 180K 5% 1/10W
(VR50)
R114 1-216-043-91 RES,CHIP 560 5% 1/10W
R115 1-216-073-00 METAL CHIP 10K 5% 1/10W
R116 1-216-091-00 METAL CHIP 56K 5% 1/10W
R117 1-216-073-00 METAL CHIP 10K 5% 1/10W
R118 1-216-089-91 RES,CHIP 47K 5% 1/10W
R119 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R120 1-216-097-91 RES,CHIP 100K 5% 1/10W
R121 1-216-073-00 METAL CHIP 10K 5% 1/10W
R122 1-216-295-91 SHORT 0
R123 1-216-101-00 METAL CHIP 150K 5% 1/10W
(VR70)
R123 1-216-107-00 METAL CHIP 270K 5% 1/10W
(VR50)
R124 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R125 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R126 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R127 1-216-101-00 METAL CHIP 150K 5% 1/10W
(VR70)
R127 1-216-111-00 METAL CHIP 390K 5% 1/10W
(VR50)
R129 1-216-121-91 RES,CHIP 1M 5% 1/10W
R131 1-216-025-91 RES,CHIP 100 5% 1/10W
R132 1-216-025-91 RES,CHIP 100 5% 1/10W
R133 1-216-025-91 RES,CHIP 100 5% 1/10W
R161 1-216-073-00 METAL CHIP 10K 5% 1/10W
R162 1-216-121-91 RES,CHIP 1M 5% 1/10W
R163 1-216-101-00 METAL CHIP 150K 5% 1/10W
(VR70)
R163 1-216-103-00 METAL CHIP 180K 5% 1/10W
(VR50)
R164 1-216-043-91 RES,CHIP 560 5% 1/10W
R165 1-216-073-00 METAL CHIP 10K 5% 1/10W
R166 1-216-091-00 METAL CHIP 56K 5% 1/10W
