– 130 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PA
R446 1-249-429-11 CARBON 10K 5% 1/4W
R447 1-249-437-11 CARBON 47K 5% 1/4W
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-412-11 CARBON 390 5% 1/4W F
R804 1-249-423-11 CARBON 3.3K 5% 1/4W F
!R805 1-216-436-00 METAL OXIDE 3.9K 5% 1W F
!R806 1-216-436-00 METAL OXIDE 3.9K 5% 1W F
!R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
!R808 1-220-893-11 METAL 0.22 10% 5W
R809 1-260-076-11 CARBON 10 5% 1/2W
R810 1-249-437-11 CARBON 47K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W F
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W F
R815 1-247-863-91 CARBON 22K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-421-11 CARBON 2.2K 5% 1/4W F
R818 1-249-417-11 CARBON 1K 5% 1/4W F
R819 1-249-439-11 CARBON 68K 5% 1/4W
!R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R821 1-249-435-11 CARBON 33K 5% 1/4W
R822 1-247-863-91 CARBON 22K 5% 1/4W
R823 1-247-863-91 CARBON 22K 5% 1/4W
R824 1-249-416-11 CARBON 820 5% 1/4W F
(VR70)
R824 1-249-418-11 CARBON 1.2K 1/4W (VR50)
!R825 1-215-891-11 METAL OXIDE 680 5% 2W F
R827 1-249-441-11 CARBON 100K 5% 1/4W
R828 1-247-903-00 CARBON 1M 5% 1/4W
R831 1-249-441-11 CARBON 100K 5% 1/4W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R833 1-249-419-11 CARBON 1.5K 5% 1/4W
(VR70)
R833 1-249-420-11 CARBON 1.8K 5% 1/4W
(VR50)
R834 1-249-429-11 CARBON 10K 5% 1/4W
R835 1-249-437-11 CARBON 47K 5% 1/4W
R836 1-249-417-11 CARBON 1K 5% 1/4W F
R837 1-249-435-11 CARBON 33K 5% 1/4W
R838 1-249-435-11 CARBON 33K 5% 1/4W
!R839 1-215-877-11 METAL OXIDE 22K 5% 1W F
R840 1-249-402-11 CARBON 56 5% 1/4W F
!R842 1-202-972-61 FUSIBLE 1 5% 1/4W F
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-412-11 CARBON 390 5% 1/4W F
!R855 1-215-891-11 METAL OXIDE 680 5% 2W F
!R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
R858 1-220-893-11 METAL 0.22 10% 5W
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-249-437-11 CARBON 47K 5% 1/4W
R861 1-249-417-11 CARBON 1K 5% 1/4W F
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
R868 1-249-417-11 CARBON 1K 5% 1/4W F
R880 1-249-402-11 CARBON 56 5% 1/4W F
!R889 1-215-877-11 METAL OXIDE 22K 5% 1W F
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-429-11 CARBON 10K 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-247-807-31 CARBON 100 5% 1/4W
R909 1-247-791-91 CARBON 22 5% 1/4W
< RELAY >
RY401 1-515-920-11 RELAY (24V)
< TERMINAL >
TM401 1-537-842-11 TERMINAL BOARD (FRONT SPEAKER)
**************************************************************
* A-4426-366-A PANEL FL BOARD, COMPLETE (VR50)
**********************
* A-4426-393-A PANEL FL BOARD, COMPLETE (VR70)
**********************
* 4-214-749-01 HOLDER (925), FL TUBE (VR70)
* 4-214-750-01 HOLDER (915), FL TUBE (VR50)
* 4-949-935-81 CUSHION (FL)
< CAPACITOR >
C601 1-104-664-11 ELECT 47uF 20% 10V
C602 1-162-306-11 CERAMIC 0.01uF 20% 16V
C604 1-126-960-11 ELECT 1uF 20% 50V
C606 1-126-960-11 ELECT 1uF 20% 50V
C608 1-104-665-11 ELECT 100uF 20% 10V
C609 1-162-294-31 CERAMIC 0.001uF 10% 50V
C611 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C612 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C613 1-104-664-11 ELECT 47uF 20% 16V
C616 1-162-294-31 CERAMIC 0.001uF 10% 50V
C617 1-162-306-11 CERAMIC 0.01uF 20% 16V
C621 1-126-964-11 ELECT 10uF 20% 50V
C622 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C623 1-126-964-11 ELECT 10uF 20% 50V
C624 1-104-664-11 ELECT 47uF 20% 16V
C625 1-126-963-11 ELECT 4.7uF 20% 50V
C626 1-126-964-11 ELECT 10uF 20% 50V
C641 1-162-286-21 CERAMIC 220PF 10% 50V
C642 1-162-286-21 CERAMIC 220PF 10% 50V
C643 1-162-286-21 CERAMIC 220PF 10% 50V
C644 1-162-286-21 CERAMIC 220PF 10% 50V
C645 1-162-286-21 CERAMIC 220PF 10% 50V
C646 1-162-286-21 CERAMIC 220PF 10% 50V
C647 1-162-286-21 CERAMIC 220PF 10% 50V
C648 1-162-286-21 CERAMIC 220PF 10% 50V
C649 1-162-286-21 CERAMIC 220PF 10% 50V
C650 1-162-286-21 CERAMIC 220PF 10% 50V
C651 1-162-286-21 CERAMIC 220PF 10% 50V
C652 1-162-286-21 CERAMIC 220PF 10% 50V
C653 1-162-286-21 CERAMIC 220PF 10% 50V
PANEL FL
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
