Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
62
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
1-676-220-11 HEAD(A) BOARD
*************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
**************************************************************
1-676-221-11 HEAD(B) BOARD
*************
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
**************************************************************
A-2007-838-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20.00% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1004 1-771-205-11 SWITCH, LEAF (A 120/70)
S1005 1-771-205-11 SWITCH, LEAF (REC A)
S1006 1-771-333-11 SWITCH, LEAF (B HALF)
S1008 1-771-205-11 SWITCH, LEAF (B 120/70)
S1009 1-771-205-11 SWITCH, LEAF (REC B)
**************************************************************
A-4428-453-A MAIN BOARD, COMPLETE
(VX55:E,IA,TW,HK,SP,MY/VX55J:JE)
*********************
A-4428-898-A MAIN BOARD, COMPLETE (VX55:EA)
*********************
A-4428-983-A MAIN BOARD, COMPLETE (VX55:TH)
*********************
A-4473-163-A MAIN BOARD, COMPLETE (VX55J:EA)
*********************
7-685-646-79 SCREW+BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C102 1-126-961-11 ELECT 2.2uF 20.00% 50V
C103 1-126-964-11 ELECT 10uF 20.00% 50V
C104 1-126-964-11 ELECT 10uF 20.00% 50V
C105 1-126-964-11 ELECT 10uF 20.00% 50V
C106 1-136-161-00 MYLAR 0.047uF 5.00% 50V
C107 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C108 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C109 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C110 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C111 1-163-018-00 CERAMIC CHIP 0.0056uF 5% 50V
C112 1-126-961-11 ELECT 2.2uF 20.00% 50V
C113 1-126-957-11 ELECT 0.22uF 20.00% 50V
C114 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
C115 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C116 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C117 1-126-964-11 ELECT 10uF 20.00% 50V
C118 1-126-961-11 ELECT 2.2uF 20.00% 50V
C119 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C120 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C121 1-126-964-11 ELECT 10uF 20.00% 50V
C122 1-126-964-11 ELECT 10uF 20.00% 50V
C123 1-126-964-11 ELECT 10uF 20.00% 50V
C124 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C126 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
C131 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C132 1-126-964-11 ELECT 10uF 20.00% 50V
C133 1-126-925-11 ELECT 470uF 20.00% 10V
C134 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C135 1-126-964-11 ELECT 10uF 20.00% 50V
C140 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C142 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C144 1-126-964-11 ELECT 10uF 20.00% 50V
C146 1-126-925-11 ELECT 470uF 20.00% 10V
C151 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
DRIVER HEAD (A) HEAD (B) MAINLEAF SW
