Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
72
S620 1-762-875-21 SWITCH, KEYBOARD (PAUSE)
S621 1-762-875-21 SWITCH, KEYBOARD (AMS-)
S622 1-762-875-21 SWITCH, KEYBOARD (PICTURE EFFECT)
S623 1-762-875-21 SWITCH, KEYBOARD (LEFT)
S624 1-762-875-21 SWITCH, KEYBOARD (RIGHT)
S625 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S626 1-762-875-21 SWITCH, KEYBOARD (STOP)
S627 1-762-875-21 SWITCH, KEYBOARD (CD)
S628 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S629 1-762-875-21 SWITCH, KEYBOARD (PLAY)
S630 1-762-875-21 SWITCH, KEYBOARD (MD(VIDEO)
S631 1-762-875-21 SWITCH, KEYBOARD (REV)
S632 1-762-875-21 SWITCH, KEYBOARD (SURROUND)
S633 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
S634 1-762-875-21 SWITCH, KEYBOARD (REPEAT)
S635 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S636 1-762-875-21 SWITCH, KEYBOARD (EDIT)
S637 1-762-875-21 SWITCH, KEYBOARD (POWER)
S638 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S639 1-762-875-21 SWITCH, KEYBOARD (EQ EDIT)
S640 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S641 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
< VIBRATOR >
X601 1-579-352-11 VIBRATOR, CERAMIC 12.5MHz
**************************************************************
A-4428-094-A POWER AMP BOARD, COMPLETE
(VX55:E,IA,EA,TW,HK,SP,MY/VX55J:JE)
***************************
A-4428-901-A POWER AMP BOARD, COMPLETE(VX55:TH)
***************************
A-4473-050-A POWER AMP BOARD, COMPLETE(VX55J:EA)
***************************
< CAPACITOR >
C501 1-126-963-11 ELECT 4.7uF 20.00% 50V
C502 1-162-294-31 CERAMIC 0.001uF 10% 50V
C503 1-162-286-21 CERAMIC 220PF 10.00% 50V
C504 1-104-665-11 ELECT 100uF 20.00% 10V
C507 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C508 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C509 1-128-560-11 ELECT 22uF 20.00% 100V
C510 1-128-578-11 ELECT 1uF 20.00% 100V
C511 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C512 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C541 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C542 1-127-753-11 ELECT 3300uF 20% 71V
C551 1-126-963-11 ELECT 4.7uF 20.00% 50V
C552 1-162-294-31 CERAMIC 0.001uF 10% 50V
C553 1-162-286-21 CERAMIC 220PF 10.00% 50V
C554 1-104-665-11 ELECT 100uF 20.00% 10V
C557 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C558 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C559 1-128-560-11 ELECT 22uF 20.00% 100V
C581 1-126-967-11 ELECT 47uF 20.00% 50V
C591 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C592 1-127-753-11 ELECT 3300uF 20% 71V
C942 1-126-964-11 ELECT 10uF 20.00% 50V
C943 1-126-968-11 ELECT 100uF 20.00% 50V
C980 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D541 8-719-302-38 DIODE RBV-602-01
D551 8-719-991-33 DIODE 1SS133T-77
D581 8-719-991-33 DIODE 1SS133T-77
D941 8-719-110-90 DIODE MTZJ-T-77-39D
D979 8-719-923-80 DIODE CL-61R-CD-271TL
< EARTH >
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-016-96 IC STK402-120S
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q505 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q506 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q941 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-414-11 CARBON 560 5% 1/4W F
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W F
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0 R508 1-217-156-00 METAL 0.22 20% 5W
R509 1-260-076-11 CARBON 10 5% 1/2W
0 R510 1-217-156-00 METAL 0.22 20% 5W
0 R511 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R512 1-202-972-61 FUSIBLE 1 5% 1/4W
R513 1-249-435-11 CARBON 33K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W F
R515 1-247-863-91 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W F
R518 1-249-435-11 CARBON 33K 5% 1/4W
R519 1-249-439-11 CARBON 68K 5% 1/4W
R521 1-249-441-11 CARBON 100K 5% 1/4W
PANEL
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
POWER AMP
Ver 1.4 2003.05
