R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-073-00 METAL CHIP 10K 5% 1/10W
R516 1-216-073-00 METAL CHIP 10K 5% 1/10W
R517 1-216-073-00 METAL CHIP 10K 5% 1/10W
R518 1-216-073-00 METAL CHIP 10K 5% 1/10W
R519 1-216-025-91 RES-CHIP 100 5% 1/10W
R520 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R521 1-216-073-00 METAL CHIP 10K 5% 1/10W
R523 1-216-013-00 METAL CHIP 33 5% 1/10W
R530 1-216-025-91 RES-CHIP 100 5% 1/10W
R531 1-216-025-91 RES-CHIP 100 5% 1/10W
R532 1-216-295-91 SHORT 0
R533 1-216-295-91 SHORT 0
R534 1-216-073-00 METAL CHIP 10K 5% 1/10W
R535 1-216-073-00 METAL CHIP 10K 5% 1/10W
R536 1-216-033-00 METAL CHIP 220 5% 1/10W
R537 1-216-025-91 RES-CHIP 100 5% 1/10W
R538 1-216-073-00 METAL CHIP 10K 5% 1/10W
R539 1-216-295-91 SHORT 0
R540 1-216-295-91 SHORT 0
R542 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R543 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R544 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R545 1-216-025-91 RES-CHIP 100 5% 1/10W
R546 1-216-049-91 RES-CHIP 1K 5% 1/10W
R548 1-216-049-91 RES-CHIP 1K 5% 1/10W
R549 1-216-025-91 RES-CHIP 100 5% 1/10W
R550 1-216-025-91 RES-CHIP 100 5% 1/10W
R551 1-216-025-91 RES-CHIP 100 5% 1/10W
R552 1-216-025-91 RES-CHIP 100 5% 1/10W
R555 1-216-121-91 RES-CHIP 1M 5% 1/10W
R556 1-216-025-91 RES-CHIP 100 5% 1/10W
R557 1-216-025-91 RES-CHIP 100 5% 1/10W
R560 1-216-653-11 METAL CHIP 1.2K 0.5% 1/10W
R561 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R562 1-216-073-00 METAL CHIP 10K 5% 1/10W
R563 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-081-00 METAL CHIP 22K 5% 1/10W
R578 1-216-081-00 METAL CHIP 22K 5% 1/10W
R579 1-216-073-00 METAL CHIP 10K 5% 1/10W
R580 1-216-073-00 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X501 1-767-510-11 VIBRATOR, CERAMIC 10MHz
X503 1-767-519-11 VIBRATOR, CRYSTAL 27MHz
**************************************************************
MISCELLANEOUS
**************
10 1-769-987-11 WIRE(FLAT TYPE) (13 CORE)(VX55)
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
104 1-773-122-11 WIRE (FLAT TYPE) (19 CORE)
0 108 1-777-071-21 CORD, POWER (VX55J:EA)
0 108 1-777-071-51 CORD, POWER (VX55:EA,TW,HK,SP,MY)
0 108 1-791-901-11 CORD, POWER (VX55:E,IA,TH/VX55J:JE)
0 109 1-569-007-11 ADAPTOR, CONVERSION (VX55:E,IA/VX55J:JE)
0 109 1-569-008-21 ADAPTOR, CONVERSION 2P
(VX55:TW,SP,MY/VX55J:EA)
0 109 1-569-008-31 ADAPTOR, CONVERSION
(VX55:EA,TW,SP,MY/VX55J:EA)
0 109 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (VX55:HK)
215 1-454-887-11 SOLENOID, PLUNGER
259 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
266 1-471-035-11 MAGNET ASSY
272 1-541-632-11 MOTOR, DC
279 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
0 281 8-820-116-01 OPTICAL PICK-UP BLOCK (KSM-213DAP)
M961 1-763-072-11 FAN, D.C.
0 T972 1-435-262-11 TRANSFORMER, POWER
**************************************************************
**************
HARDWARE LIST
**************
#1 7-628-254-05 SCREW +PS 2.6X5
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#5 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#6 7-685-881-09 SCREW +BVTT 4X8 (S)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
